8 Connecting Devices
Connecting Antenna
or Cable without a Box
ANT
TV Panel
L
Pb Y/ VIDEO Pr
INPUT
INPUT
Pb Y/ VIDEO Pr
TV Panel
AVR
AUDIO
DVI/PC INPUT
R - AUDIO - L
Cable TV
service
Antenna
Direct cable
(no cable box)
or
Mitsubishi recommends using coaxial antenna
cable instead of flat twin lead antenna wires for
better performance.
Recording to a Device from
Antenna or Cable without a Box
Required: 1. Two-way RF splitter
2. Two coaxial cables
3. Right and left analog audio cables
4. Composite video cable
P Y/ VIDEO
ANT
TV Panel
L
R
P b Pr
INPUT
INPUT
Pb Y/ VIDEO Pr
TV Panel
DIGITAL
AUDIO
OUTPUT
AVR
AUDIO
OUTPUT
DVI/PC INPUT
R - AUDIO - L
2
2
4 3
1
Incoming
cable
R - AUDIO - L Y/VIDEO
ANTENNA
IN
Connecting A/V Receiver
for TV’s Audio Output
Required: 1. Digital audio cable OR
2. Analog stereo audio cables
COAXIAL
INPUT
OPTICAL
INPUT
IN
VCR TV DVD
IN
DIGITAL AUDIO
1
1
2
L
R
b Y/ VIDEO Pr
INPUT
INPUT
Pb Y/ VIDEO Pr
HDMI
ANT
TV Panel
DIGITAL
AUDIO
OUTPUT
AVR
AUDIO
OUTPUT
DVI/PC INPUT
R - AUDIO - L
A/V Receiver
2
Digital Coaxial Cable:
Use to connect a
digital A/V receiver.
Stereo Analog Cables:
Use to connect an
analog A/V receiver.
OR
Note:
If the audio is missing from the digital audio con- •
nection, it might be due to the copy-protected
signal. Use the analog audio connection.
Check the A/V receiver’s Owner’s Guide for infor- •
mation concerning use of the digital input and
switching between digital sound and analog stereo
sound from the TV.
Connecting A/V Receiver for TV
Video and Audio Output
Required: HDMI-to-HDMI cable
Note: This setup allows you to use NetCommand-con-
trolled audio and video switching over the HDMI cable.
HDMI OUT
A/V receiver
with HDMI
output
Any
connection
type
A/V Device
Pb Y/ VIDEO Pr
INPUT
R - AUDIO - L (480i / 480p / 720p / 1080i)
TV Panel
L
R
Pb Y/ VIDEO Pr
INPUT
INPUT
Pb Y/ VIDEO Pr
ANT
TV Panel
AVR
AUDIO
OUTPUT
DVI/PC INPUT
R - AUDIO - L
