6
TV Connector Panel Diagrams
Connector Performance
GOOD BEST
VIDEO QUALITY
GOOD BEST
AUDIO QUALITY
HDMI-to-DVI HDMI
Component
Video
Composite
Video L/R Analog Digital Audio
HDMI Connectors Audio Connectors
(RCA type)
Cable Connectors
(RCA type)
Note: The number of inputs/outputs
shown TV Panel diagram may vary
from those on purchased model.
Note: USB and HDMI 4 are
available for 837 series only.
1 2 3
HDMI
AVR
AUDIO
OUTPUT
L
R
Pb Y/ VIDEO Pr
Pb Pr
INPU
T 2
INPU
T 1
DIGITAL
AUDIO
OUTPUT
DVI/PC
R–AUDIO–L
R–AUDIO–L
(480i / 480p / 720p / 1080i)
INPUT
Y/ VIDEO
3D
GLASSES
EMITTER
ANT
RS-232C
IR- NetCommand
Output
Pb Pr L–AUDIO–R USB HDMI 4 Y/ VIDEO
INPUT 3
Main connector panel
Side connector panel
