7
Connecting with Component Video
Required:
1. Component video cables
2. Left/Right Analog Audio cable.
Pb
Y/ VIDEO
Pr
INPUT
TV Panel
L
R
INPUT
Pb
Y/ VIDEO
Pr
ANT
TV Panel
AVR
AUDIO
OUTPUT
DVI/PC INPUT
R - AUDIO - L
From cable
service or
satellite dish
1
2
Pb
Y/ VIDEO
Pr
INPUT
R - AUDIO - L
(480i / 480p / 720p / 1080i)
Connecting with HDMI or DVI
Required:
1. HDMI-to-HDMI cable
OR
2. a. DVI-to-HDMI cable
AND
b. Left/Right Analog Audio cable
HDMI
TV Panel
DVI/PC INPUT
R - AUDIO - L
L
R
Pb
Y/ VIDEO
Pr
INPUT
INPUT
Pb
Y/ VIDEO
Pr
HDMI
ANT
TV Panel
DIGITAL
AVR
AUDIO
OUTPUT
DVI OUT
Pb
Y/ VIDEO
Pr
INPUT
R - AUDIO - L
(480i / 480p / 720p / 1080i)
2b
2a
1
OR
Connecting with Composite Video
VCR or other device with composite video output
Required:
1. Composite video cable
2. Left/Right Analog Audio cable
2
1
From cable
service or
satellite dish
R - AUDIO - L
Y/VIDEO
L
Pb
Y/ VIDEO
Pr
INPUT
INPUT
Pb
Y/ VIDEO
Pr
ANT
TV Panel
AVR
DVI/PC INPUT
R - AUDIO - L
Connecting Devices
