- 11 -
Mounting Dimensions (unit=mm)
Rear View
Side View
Front View
Wall Mounting Kit
DlN-Rail Kit
DlN-Rail Kit
DlN-Rail
105.00
10
10
5
7.75
30.50
7.75
9.00
0
0.
5
3
40.00 30.00
0 0.
5 3
1
9
2.
5
2
13 18 13
0
2.
7
2
0
3.
8
4
4
5.
9
3
1
6.
6
4
6
5.
3
2
0 0.
5 3
1
13.10
15.10
25.40
3.5
6
6
0 8.
6 6
5
0.
7
5
13.9 18.2 13.9
DIN-Rail Mounting
The aluminum DIN-Rail attachment plate should already be attached to the
back panel of the VPort 351 when you take it out of the box. If you need to
reattach the DIN-Rail attachment plate to the VPort 351, make sure the stiff
metal spring is situated towards the top, as shown in the figures below.
STEP 1:
Insert the top of the DIN-Rail into the
slot just below the stiff metal spring. STEP 2:
The DIN-Rail attachment unit will snap
into place as shown below.
metal
spring
DIN-Rail
metal
spring
DIN-Rail
Reverse Steps 1 and 2 above to remove the VPort 351 from the DIN-Rail.
