OWNER’S MANUAL
PARTS LIST
70,000 BTU/HR
This list contains replaceable parts used in your heater. When ordering parts, be sure to
provide the correct model and serial numbers (from the model plate), then the part number
and description of the desired part.
KEY
PART
PART
NO.
NUMBER
DESCRIPTION
QTY.
1
M51104-01
Handle
1
2
098511-54
Upper Shell
1
3
102432-01
Screw/Lockwasher, 1/2"
6
4
098512-44
Combustion Chamber
1
5
M11084-29
Screw, #10-16 x 3/4"
2
6
M16660
Photocell Bracket
1
7
M10908-2
Screw, #6-32 x 3/8"
2
8
HA3019
Photocell Assembly
1
9
079673-06
Power Cord
1
10
**
Burner Head Assembly
1
10-1
HA3008
Nozzle
1
10-2
M10659-1
Nozzle Seal Washer
2
10-3
M10809-1
Nozzle Seal Spring
1
10-4
M8882
Nozzle Seal Sleeve
1
10-5
M51098-02
Burner Head Body
1
10-6
M50820-01
Barb Fitting
2
10-7
HA3012
Spark Plug
1
11
102431-01
Screw/Lockwasher, 1/2"
11
12
M30865-02
Bushing
2
13
M50400
Strain Relief Bushing
1
14
M30884
Fan
1
15
M50631
Rubber Bumper
2
16
M12461-13
Screw, #8-32 x 1/4"
2
(holds relay in position)
17
101205-01
Motor/Relay Bracket
1
18
**
Motor and Pump Assembly
1
18-1
102001-16
Motor (230V/50Hz)
1
18-2
079975-02
Pump Body
1
18-3
M22009
Insert
1
18-4
M22456-1
Rotor
1
18-5
M29608
End Pump Cover
1
18-6
M29632
Lint Filter
1
18-7
M29633
Intake Filter
1
18-8
M29609
End Filter Cover
1
18-9
M12461-31
Screw, #10-32 x 1"
3
18-10 M8940
Steel Ball (1/4" Dia.)
1
18-11 M10993-1
Pressure Relief Spring
1
18-12 M27694
Adjusting Screw
1
18-13 M22997
Plug
1
18-14 M29612-01
Output Filter
1
**Not available as an assembly, order parts separately.
KEY
PART
PART
NO.
NUMBER
DESCRIPTION
QTY.
18-15 M12461-31
Screw, #10-32 x 1"
6
18-16 M50016
Elbow, 90˚ (Barb Fitting)
1
18-17 M8643
Blade
4
18-18 FHPF3-5C
Screw, #10-32 x 5/8"
2
19
M51105-01
Fan Guard
1
20
NTC-4C
Hex locknut
2
21
M50104-02
Bushing (wires)
2
22
102801-01
Power Line RFI Filter
1
23
098511-12
Lower Shell
1
24
M11271-8
Clip Nut
6
25
098136-05
Relay (motor start)
1
26
M16841-58
Wire Assembly (red 9 1/2")
1
27
RF3-6B
Screw, #10-32 x 3/4"
1
28
M29652-04
Rubber Airline
1
29
079973-01
Fuel Line
1
30
M16841-57
Wire Assembly (red 8 1/2")
1
31
M10990-3
Rubber Bushing
1
32
M50876-05
Fuel Filter Assembly
1
(Includes bushing)
33
102482-02
Electronic Ignitor
1
34
M11084-29
Screw, #10-16 x 3/4"
2
35
099125-02
Terminal Board
1
36
099157-01
Rivet
1
37
097702-01
Fuel Tank Cap
1
38
097630-02
Flame-Out Control
1
39
098513-74
Fuel Tank
1
40
M50899-03AA
Side Cover
1
41
NPF-3B
Nut, #10-32
3
42
099177-01
Hex Nut
1
43
078918-01
Terminal Board Tab Cap
1
44
097785-01
Vinyl Foam Gasket
1
45
WLE-3
Lock Washer, #10
2
PARTS AVAILABLE - NOT SHOWN
HA2210
Filler Neck Screen
1
097649-01
Tradename Decal
2
M9900-192
Combustion Chamber
Ground Wire
1
102944-02
Decal Package
1
