Exploded Parts-MKG Griddle Gas Models (All Options)

L22-288 Rev 0 (04/06)

6

Griddle Assembly Exploded View A1 Parts List

ITEM #

PART #

PART DESCRIPTION

1

5425-1529301 Cabinet, Burner Upright Divider MKG

2

P0075400

Screw, 10-24 x ½” Self Tap

3

5425-1531301 Cabinet, Burner Mounting Bracket

4

P0076100

Screw, 10-24 x3/4” Self Tap

5

60138901

Burner, 1.25” Diameter

6

5425-1522301 Burner, Mounting Bracket front MKG

7

PP10196

Nut, 8-32 UNC

5425-1531201 Cabinet, Burner Mounting Plate MKG
5425-1531202 Cabinet, Burner Mounting Plate MKG LH Trough

9

5425-1530303 Cabinet, Burner Seal Plate MKG L/R Pilot

10

5425-1530302 Cabinet, Burner Seal Plate MKG Mid Pilot

11

5425-1530301 Cabinet, Burner Seal Plate MKG Mid

12

5425-1533201 Burner, Manifold Retainer Bracket MKG EI

13

5425-1529201 Pilot, Cover Plate MKG
5125-1509401 W/A, Runner Tube LH MKG
5125-1532801 W/A, Runner Tube LH with Side Chute MKG

15

5125-1509402 W/A, Runner Tube RH MKG
5225-1521801 C/A, Pilot Assy. MKG with Piezo Ignition
5225-1521802 C/A, Pilot Assy. MKG Nat with Matchless Ignition
5225-1521803 C/A, Pilot Assy. MKG LP with Matchless Ignition
5425-1530401 Cabinet, Shelf Seal Plate MKG Outer
5425-1530404 Cabinet, Shelf Seal Plate MKG Side Trough

18

5425-1530403 Cabinet, Shelf Seal Plate MKG Center
5425-1519101 Cabinet, Bottom Outer MKG24
5425-1519102 Cabinet, Bottom Outer MKG36
5425-1519103 Cabinet, Bottom Outer MKG48
5425-1519104 Cabinet, Bottom Outer MKG60
5425-1519105 Cabinet, Bottom Outer MKG72
5125-1519201 W/A, Cabinet Bottom Front and Rear MKG24
5125-1519202 W/A, Cabinet Bottom Front and Rear MKG36
5125-1519203 W/A, Cabinet Bottom Front and Rear MKG48
5125-1519204 W/A, Cabinet Bottom Front and Rear MKG60
5125-1519205 W/A, Cabinet Bottom Front and Rear MKG72
5425-1519001 Cabinet, Bottom Support MKG24
5425-1519002 Cabinet, Bottom Support MKG36
5425-1519003 Cabinet, Bottom Support MKG48
5425-1519004 Cabinet, Bottom Support MKG60
5425-1519005 Cabinet, Bottom Support MKG72

21

20

8

14

16

19

17
