Exploded Parts-MKG Griddle Gas Models (All Options)
L22-288 Rev 0 (04/06) 14
D) GAS CONTROL PIPING
Snap Action with Piezo Ignition Gas Assembly Exploded View D Parts List
ITEM # PART # PART DESCRIPTION
1 P6071767 Valve, Manual Shut Off, ½” NPT
2 P70366605 Coupling, ½” NPT Mild Steel
3 60148201 Nipple, ½” x 12” NPT Blk Iron
4 60127601 Fitting, Brass ½” MNPT x Fem Swivel
5 60139101 Valve, Gas Safety Single T-Couple
6 P7037090 Nipple, ½” Close NPT Blk Iron
7 A8033101 Piping, Tee ½” FNPT x 15/16” Flare
8 A8029105 Coupling, Gas Supply, SG MKG
9 P7037750 Elbow, ½” Street NPT
10 60139401 Fitting, Straight Compression 1/4” NPT x 3/8” Tube
11 P7036855 Tee, ½” NPT Blk Iron
12 PP11056 Bushing, Reducer Hex ½” NPT x ¼” NPT
13 PP11134 Fitting, Elbow Compression ¼” NPT x 3/8” Tube
14 60129902 Fitting, Adapter Male Flare 45 x ½” MNPT (MKG60 & 72 Only)
15 60128001 Tube, Flexible w/ Fittings 16”(MKG60 & 72 Only)
16 60129301 Screw, 10-24 x 5/8” Mach HH ZN w/ Loc Tite
2701-0028200 Regulator, Natural Gas 3.0”-5.0”
2701-0028300 Regulator, Propane Gas 5.0”-12.0”
5225-1520001 Manifold, Main Burner MKG
5225-1520002 Manifold, Main Burner MKG Left Hand Trough
2908-1318207 Orifice, Natural Gas 5/64”
2908-1318208 Orifice, Propane Gas 1.15 MM
20 5425-1537701 Piping, Gas Bracket Stiffener Retainer
21 5425-1537801 Piping, Gas Bracket Stiffener
22 P0075400 Screw, 10-24 x ½” Self Tap
23 5425-1531401 Bracket, Gas Supply Pipe Inlet
17
18
19
