Exploded Parts-MKG Griddle Gas Models (All Options)
L22-288 Rev 0 (04/06) 16
Matchless Ignition Gas Assembly Exploded View D1 Parts List
ITEM # PART # PART DESCRIPTION
60141901 Control, Ignition Spark/Sense 120V w/o Cover
60141902 Control, Ignition Spark/Sense 120V w/ Cover
2 P0091400 Nutsert, 6-32 UNC THD
3 P0075400 Screw, 10-24 x ½” Self Tap
4 5425-1523302 Bracket, Ignition Control Module L/R
5 5425-1529501 Bracket, Component MKG EI
6 60086401 Fitting, Brass Compression 3/8” TU x 3/8” NPT
7 PP10690 Screw, 6-32 x ½” UNC THD
8 5425-1523801 Bracket, Piping Solenoid
9 P7036727 Plug, 3/8” NPT Steel
10 60142001 Valve, Dual Port 120 VAC
11 P7037301 Nipple, 3/8” Close NPT Blk Iron Pipe
12 60142101 Valve, Single Port 120 VAC
13 P7037797 Elbow, Brass Compression 1/8” TU x1/4” NPT
14 P7037675 Elbow, 90° 3/8” Blk Iron Pipe
15 P7037313 Nipple, 3/8” x 6-1/2” NPT Blk Iron Pipe
16 P7036901 Union, 3/8” NPT Blk Iron Pipe
17 P7036854 Tee, 3/8” NPT Blk Iron Pipe
18 60122902 Fitting, Male Adapter Flare 45 x ½”
19 P7036860 Tee, 3/4” NPT Blk Iron Pipe
20 60127601 Fitting, Brass ½” MNPT x Fem Swivel
21 60128001 Tube, Flexible w/ Fittings 16”(MKG60 & 72 Only)
2701-0028200 Regulator, Natural Gas 3.0”-5.0”
2701-0028300 Regulator, Propane Gas 5.0”-12.0”
23 P7037350 Nipple, 3/4” Close NPT Blk Iron Pipe
24 PP11095 Valve, Manual Shut Off,3/4” NPT
25 P7037679 Elbow, 90° 3/4” Blk Iron Pipe
26 60129301 Screw, 10-24 x 5/8” Mach HH ZN w/ Loc Tite
27 5425-1531401 Bracket, Gas Supply Pipe Inlet
28 A8029105 Coupling, Gas Supply, SG MKG
5225-1520001 Manifold, Main Burner MKG
5225-1520002 Manifold, Main Burner MKG Left Hand Trough
2908-1318207 Orifice, Natural Gas 5/64”
2908-1318208 Orifice, Propane Gas 1.15 MM
1
22
29
30
