Exploded Parts-MKG Griddle Gas Models (All Options)
L22-288 Rev 0 (04/06) 4
A) GRIDDLE ASSEMBLY
Griddle Assembly Exploded View A Parts List
ITEM # PART # PART DESCRIPTION
5125-1536701 Weld Assembly, MKG24 Plain Steel Griddle Top
5125-1536702 Weld Assembly, MKG36 Plain Steel Griddle Top
5125-1536703 Weld Assembly, MKG48 Plain Steel Griddle Top
5125-1536704 Weld Assembly, MKG60 Plain Steel Griddle Top
5125-1536705 Weld Assembly, MKG72 Plain Steel Griddle Top
5125-1536706 Weld Assembly, MKG24 Chrome Plated Griddle Top
5125-1536707 Weld Assembly, MKG36 Chrome Plated Griddle Top
5125-1536708 Weld Assembly, MKG48 Chrome Plated Griddle Top
5125-1536709 Weld Assembly, MKG60 Chrome Plated Griddle Top
5125-1536710 Weld Assembly, MKG72 Chrome Plated Griddle Top
5125-1516601 Weld Assembly, MKG24 Plain Steel Griddle Top, LH Trough
5125-1516602 Weld Assembly, MKG36 Plain Steel Griddle Top, LH Trough
5125-1516603 Weld Assembly, MKG48 Plain Steel Griddle Top, LH Trough
5125-1516604 Weld Assembly, MKG60 Plain Steel Griddle Top, LH Trough
5125-1516605 Weld Assembly, MKG72 Plain Steel Griddle Top, LH Trough
5125-1516606 Weld Assembly, MKG24 Chrome Plated Griddle Top, LH Trough
5125-1516607 Weld Assembly, MKG36 Chrome Plated Griddle Top, LH Trough
5125-1516608 Weld Assembly, MKG48 Chrome Plated Griddle Top, LH Trough
5125-1516609 Weld Assembly, MKG60 Chrome Plated Griddle Top, LH Trough
5125-1516610 Weld Assembly, MKG72 Chrome Plated Griddle Top, LH Trough
5125-1537101 Weld Assembly, MKG24 Plain Steel Griddle Top, RR Trough
5125-1537102 Weld Assembly, MKG36 Plain Steel Griddle Top, RR Trough
5125-1537103 Weld Assembly, MKG48 Plain Steel Griddle Top, RR Trough
5125-1537104 Weld Assembly, MKG60 Plain Steel Griddle Top, RR Trough
5125-1537105 Weld Assembly, MKG72 Plain Steel Griddle Top, RR Trough
5125-1537106 Weld Assembly, MKG24 Chrome Plated Griddle Top, RR Trough
5125-1537107 Weld Assembly, MKG36 Chrome Plated Griddle Top, RR Trough
5125-1537108 Weld Assembly, MKG48 Chrome Plated Griddle Top, RR Trough
5125-1537109 Weld Assembly, MKG60 Chrome Plated Griddle Top, RR Trough
5125-1537110 Weld Assembly, MKG72 Chrome Plated Griddle Top, RR Trough
5425-1531001 Cabinet Back, Removable MKG24
5425-1531002 Cabinet Back, Removable MKG36
5425-1531003 Cabinet Back, Removable MKG48
5425-1531004 Cabinet Back, Removable MKG60
5425-1531005 Cabinet Back, Removable MKG72
3 P0020600 Bolt, ¼-20 UNC x ½” Thread
4 P0075400 Screw, 10-24 x ½” Self Tap
5 5425-1540301 Cabinet, Back Spacer Bracket MKG
5425-1529701 Cabinet Back, Removable W/Flue MKG24
5425-1529702 Cabinet Back, Removable W/Flue MKG36
5425-1529703 Cabinet Back, Removable W/Flue MKG48
5425-1529704 Cabinet Back, Removable W/Flue MKG60
5425-1529705 Cabinet Back, Removable W/Flue MKG72
1
2
6
