Specifications

Product Specifications

Analog Input

Digital Input

LCD Module

Diagonal:

32" / 80.0cm

Pixel Pitch:

0.511mm

Resolution:

1366 x 768 dots

Color:

Over 16 million colors (depending on video card used)

Brightness:

500cd/m

(Typ.)

Contrast Ratio:

600:1

Response time:

20ms (Tr+Tf)

Viewing Angle:

Up 88°/ Down 88°/ Left 88°/ Right 88° (typ) @ CR>10

Design View Distance:

875 mm/34.4 inches

Frequency

Horizontal:

15.625/15.734kHz, 31.5kHz - 91.1kHz

31.5kHz - 91.1kHz

Vertical:

50.0/58.0 - 85.0 Hz

Pixel Clock

25.0MHz - 162.0MHz

Viewable Size

392.3 x 697.7 mm/15.4 x 27.5 inches

Input Signal

PC-Input:

Video:

Analog RGB Video 0.7V p-p

TMDS

Input Impedance 75 ohm
Composite sync on Green Video: 0.3Vp-p Neg. (video 0.7Vp-p Pos.)

Sync:

Separate HV sync: TTL level (Pos./ Neg.)
Input Impedance 2.2K ohm (RGB3: 2.2k ohm/75 ohm selectable)

Input-terminal:

BNC (R,G,B,H,V) 15pin Mini D-sub

DVI-D (Digital)

VIDEO Input:

Composite 1.0V p-p Input Impedance 75 ohm BNC and RCA-INPUT
Y/C Y:0.7V p-p C:0.283V p-p Input Impedance 75 ohm S-TERMINAL-INPUT
Component 1.0/0.7V p-p Input Impedance 75 ohm BNC-INPUT

AUDIO Input:

RCA PIN-JACK L/R INPUT, STEREO Mini Jack INPUT

RS-232C:

In:

9 Pin Mini D-sub

Output Signal

PC-Output:

Video:

Analog RGB Video: 0.7V p-p with 75 ohm terminated

Sync:

Separate HV sync: TTL level (Posi / Nega) with 2.2k ohm terminated

Output-terminal:

Mini D-sub 15Pin

VIDEO Output:

BNC 1 Output, Composite 1.0V p-p with 75 ohm terminated

AUDIO Output:

RCA PIN-JACK L/R: 1 Output, 0.15Vrms with 1k ohm terminated

Speaker Output:

External Speaker Jack 7W + 7W

Resolutions Supported

640 x 480 at 60Hz to 85Hz
800 x 600 at 50Hz, 60Hz to 85Hz
1024 x 768 at 50Hz, 60Hz to 85Hz
1280 x 768 at 50Hz, 60Hz to 85Hz
1360 x 768 at 50Hz, 60Hz* to 85Hz
1280 x 1024 at 60Hz to 85Hz
1600 x 1200 at 60Hz....................................................... Maximum Resolution

* Recommended Resolution

NTSC/PAL/SECAM/4.43NTSC/PAL60 Component: 480i, 480p, 720p, 1080i

Power Supply

1.4 - 0.6A @ 100-240VAC, 50/60Hz

Power Consumption

Max.140W

Power save:

Less than 4W (Power button OFF/Main power switch ON)

Operational

Temperature:

5 - 40°C/41 - 104°F

Environment

Humidity:

20 - 80% (without condensation)

Storage

Temperature:

-20 - 60°C/-4 - 140°F

Environment

Humidity:

10 - 90% (without condensation)/ 90% - 3.5% x (Temp - 40°C) regarding over 40°C

Dimension

Net:

789 (W) x 479 (H) x 140 (D) mm/31.1 (W) x 18.9 (H) x 5.5 (D) inches (without Stand)
789 (W) x 510.3 (H) x 200 (D) mm/31.1 (W) x 20.1 (H) x 7.9 (D) inches (with Stand)

Gross:

944 (W) x 652 (H) x 312 (D) mm/37.2 (W) x 25.7 (H) x 12.3 (D) inches

Weight

Net:

33.5 lbs/15.2 kg (without Stand)
36.2 lbs/16.4 kg (with Stand)

Gross:

49.6 lbs/22.5 kg

VESA compatible arm

3 x 200mm x 200mm (8 Holes)

mounting interface

2 x 200 mm x 200 mm (6 Holes)

Complied Regulatory and

UL60950-1/CSA C22.2 No.60950-1/ TUV-GS/EN60950-1

Guidelines

FCC-B/DOC-B/EN55022-A/EN55024/EN61000-3-2/EN61000-3-3/CE

Power Management

VESA DPM

Plug & Play

VESA DDC2B, DDC/CI

Accessories

User’s manual, Power Cord x2, Video Signal Cable, Remote Control, AA Battery x 2,
Clamper x 3, Screw x 4, CD-ROM, Ferrite Core x 2, Stand for the Independence x 2,
Curled head Screw for stand x 2, Band x 2, Speaker plug x 1set, Main power switch cover

NOTE: Technical specifications are subject to change without notice.
