1-25
English-23
English
Select “SCREEN SAVER” functions to reduce the risk of
the “image persistence”.
GAMMA: The display gamma is changed and fixed when
selected “ON”.
COOLING FAN: The built in cooling fan is always on
when set “ON”.
BRIGHTNESS: The brightness is decreased when
selected “ON”.
MOTION: Image is slightly expanded and moves
4 directions (UP, DOWN, RIGHT, LEFT) periodically
(Need setting the time for movement).
Movement area is approximately +/- 10mm from original
position; Please locate the important information such as
text within 90% area of screen image.
See note (1) for this functions.
PIP and STILL will be disabled when “MOTION” is active.
Selecting the Color System depends on your input video
format.
AUTO: NTSC, PAL, SECAM, PAL60 or 4.43 NTSC is
automatically selected.
NTSC: Specific selection of NTSC.
PAL: Specific selection of PAL.
SECAM: Specific selection of SECAM.
PAL-60: Specific selection of PAL60.
4.43NTSC: Specific selection of 4.43 NTSC.
Adjustment the side black bar color white when 4:3
image displayed, black to white.
Press + button, the bar will become whiter.
Press - button, the bar will become darker.
Selecting the CONFIGURATION RESET allows you to
reset all configuration settings.
Select “Yes” and press “SET” button to restore the factory
preset data.
Press “EXIT” button to cancel and return the previous
menu.
Selecting “YES” allows you to reset PICTURE, SCREEN,
AUDIO, CONFIGURATION1,2 and ADVANCED OPTION
will be back to factory settings (except LANGUAGE,
DATE & TIME and SCHEDULE).
Select “YES” and press “SET” button to restore the
factory preset data.
Press “EXIT” button to cancel and return the previous
menu.
SCREEN SAVER
COLOR SYSTEM
*:INPUT VIDEO only
SIDE BORDER
COLOR
CONFIGURATION
RESET
FACTORY RESET
CONFIGURATION 1
POWER SAVE
LANGUAGE
SCREEN SAVER
COLOR SYSTEM
SIDE BORDER COLOR
CONFIGURATION RESET
FACTORY RESET
:SEL SET :NEXT :RETURN MENU :EXIT MENU EXIT
FACTORY RESET
:RETURN MENU :EXIT MENU
NO
YES
:SEL EXIT
CONFIGURATION 1
POWER SAVE
LANGUAGE
SCREEN SAVER
COLOR SYSTEM
SIDE BORDER COLOR
CONFIGURATION RESET
FACTORY RESET
:SEL SET :NEXT :RETURN MENU :EXIT MENU EXIT
CONFIGURATION RESET
:RETURN MENU :EXIT MENU
NO
YES
:SEL EXIT
CONFIGURATION 1
AUTO SETUP
AUTO ADJUST
AUTO BRIGHTNESS
POWER SAVE
LANGUAGE
SCREEN SAVER
SIDE BORDER COLOR
:SEL SET :NEXT :RETURN MENU :EXIT MENU EXIT + -:ADJ EXIT :RETURN
SCREEN SAVER
:SEL
GAMMA
COOLING FAN
BRIGHTNESS
MOTION
ON / OFF
ON / AUTO
ON / OFF
10 SEC.
CONFIGURATION 1
POWER SAVE
LANGUAGE
SCREEN SAVER
COLOR SYSTEM
SIDE BORDER COLOR
CONFIGURATION RESET
FACTORY RESET
:SEL SET :NEXT :RETURN MENU :EXIT MENU EXIT
COLOR SYSTEM
AUTO DEUTSCH
NTSC
PAL
SECAM
4.43 NTSC
PAL-60
:SEL :RETURN MENU :EXIT MENU EXIT
CONFIGURATION 1
AUTO BRIGHTNESS
POWER SAVE
LANGUAGE
POWER SAVE
COLOR SYSTEM
SIDE BORDER COLOR
CONFIGURATION RESET
FACTORY RESET
:SEL SET :NEXT :RETURN MENU :EXIT MENU EXIT
+ -:ADJ :RETURN MENU :EXIT MENU
50
SIDE BORDER COLOR
EXIT
Main-Menu
CONFIGURATION 2
Sub-Menu
To compensate for image degradation, which is caused by
using a long cable.
VIDEO EQ
To optimize the shape (Tailing) of RED, GREEN and
BLUE signal.
Level: 0 - 7
SYNC TERMINATE (Input RGB 3 only)
To select the terminate resistance for matching the cable
impedance.
HI: 2.2K ohm/LO:75 ohm
LONG CABLE
MANUAL
*:INPUT RGB2/3 only
MAIN MENU
SCREEN
AUDIO
PIP
CONFIGURATION 1
CONFIGURATION 2
ADVANCED OPTION
:SEL SET :NEXT :RETURN MENU :EXIT MENU EXIT
CONFIGURATION 2
LONG CABLE MANUAL
OSD TURN OFF
INFORMATION OSD
OFF TIMER
OSD POSITION
INPUT DETECT
MONITOR INFORMATION
:SEL SET :NEXT EXIT :RETURN MENU :EXIT MENU
LONG CABLE MANUAL
VIDEO EQ.
SYNC TERMINATE
:SEL NEXT :RETURN + -:ADJ
0
HI / LO
