1-22
English-20
Adjust the tint of the screen.
Press + button to Skin color becomes greenish.
Press - button to Skin color becomes purplish.
Adjust the color depth of the screen.
Press + button to increase color depth.
Press - button to decrease color depth.
R, G, B: Increases or decreases Red, Green and Blue,
depending upon which is selected. The change in color
will appear on screen and the direction (increase or
decrease) will be shown by the color bars.
NOTE: sRGB picture mode is standard and cannot be
changed.
To adjust the color temperature of entire screen.
Adjusting lower color temperature makes the screen
reddish and higher color temperature makes the screen
bluish.
NOTE: sRGB picture mode is standard and cannot be
changed.
Selecting Picture reset allows you to reset all OSD
settings about PICTURE setting.
Select “Yes” and press “SET” button to restore to factory
preset data.
Press “EXIT” button to cancel and then return to the
previous menu.
TINT
*:INPUT DVD/HD, VIDEO only
COLOR
*:INPUT DVD/HD, VIDEO only
COLOR CONTROL
*:INPUT RGB1,2,3 only
COLOR
TEMPERATURE
PICTURE RESET
BRIGHTNESS
CONTRAST
SHARPNESS
BLACK LEVEL
COLOR CONTROL
COLOR TEMPERATURE
PICTURE RESET
:SEL SET :NEXT :RETURN MENU :EXIT MENU EXIT
PICTURE RESET
:RETURN MENU :EXIT MENU
NO
YES
:SEL EXIT
BRIGHTNESS
CONTRAST
SHARPNESS
BLACK LEVEL
COLOR CONTROL
COLOR TEMPERATURE
PICTURE RESET
:SEL SET :NEXT :RETURN MENU :EXIT MENU EXIT
+ -:ADJ :RETURN MENU :EXIT MENU
9600K
COLOR TEMPERATURE
EXIT
BRIGHTNESS
CONTRAST
SHARPNESS
BLACK LEVEL
COLOR CONTROL
COLOR TEMPERATURE
PICTURE RESET
:SEL SET :NEXT :RETURN MENU :EXIT MENU EXIT + -:ADJ EXIT :RETURN
COLOR CONTROL
255
:SEL
RED
255 GREEN
255 BLUE
BRIGHTNESS
CONTRAST
SHARPNESS
TINT
COLOR
BLACK LEVEL
NOISE REDUCTION
:SEL SET :NEXT :RETURN MENU :EXIT MENU EXIT
+ -:ADJ :RETURN MENU :EXIT MENU
32
COLOR
EXIT
BRIGHTNESS
CONTRAST
SHARPNESS
TINT
COLOR
BLACK LEVEL
NOISE REDUCTION
:SEL SET :NEXT :RETURN MENU :EXIT MENU EXIT
+ -:ADJ :RETURN MENU :EXIT MENU
32
TINT
EXIT
Main-Menu
SCREEN
Sub-Menu
Controls Horizontal Image position within the display
area of the LCD.
Press + button to move screen to right.
Press - button to move screen to left.
Controls Vertical Image position within the display
area of the LCD.
Press + button to move screen to UP.
Press - button to move screen to DOWN.
Press + button to expand the width of the image on
the screen to the right.
Press - button to narrow the width of the image on the
screen to the left.
Improves focus, clarity and image stability by increasing
or decreasing this setting.
Adjusts the horizontal size by increasing or decreasing
the setting.
Press + button to expand the width of the image on
the screen.
Press - button to narrow the width of the image on
the screen.
H POSITION
V POSITION
CLOCK
*:INPUT RGB2/3 only
CLOCK PHASE
*:INPUT RGB2/3, DVD/HD only
H RESOLUTION
*:INPUT RGB1/2/3 only
MAIN MENU
SCREEN
AUDIO
PIP
CONFIGURATION 1
CONFIGURATION 2
ADVANCED OPTION
:SEL SET :NEXT :RETURN MENU :EXIT MENU EXIT
SCREEN
H POSITION
V POSITION
CLOCK
CLOCK PHASE
H RESOLUTION
V RESOLUTION
ZOOM MODE
SCREEN RESET
:SEL SET :NEXT :RETURN MENU :EXIT MENU EXIT
+ -:ADJ :RETURN MENU :EXIT MENU
1360
H RESOLUTION
EXIT
SCREEN
H POSITION
V POSITION
CLOCK
CLOCK PHASE
H RESOLUTION
V RESOLUTION
ZOOM MODE
SCREEN RESET
:SEL SET :NEXT :RETURN MENU :EXIT MENU EXIT
+ -:ADJ :RETURN MENU :EXIT MENU
18
CLOCK PHASE
EXIT
SCREEN
H POSITION
V POSITION
CLOCK
CLOCK PHASE
H RESOLUTION
V RESOLUTION
ZOOM MODE
SCREEN RESET
:SEL SET :NEXT :RETURN MENU :EXIT MENU EXIT
+ -:ADJ :RETURN MENU :EXIT MENU
1782
CLOCK
EXIT
SCREEN
H POSITION
V POSITION
CLOCK
CLOCK PHASE
H RESOLUTION
V RESOLUTION
ZOOM MODE
SCREEN RESET
:SEL SET :NEXT :RETURN MENU :EXIT MENU EXIT
+ -:ADJ :RETURN MENU :EXIT MENU
10
V POSITION
EXIT
+ -:ADJ :RETURN MENU :EXIT MENU
10
H POSITION
EXIT
SCREEN
H POSITION
V POSITION
CLOCK
CLOCK PHASE
H RESOLUTION
V RESOLUTION
ZOOM MODE
SCREEN RESET
:SEL SET :NEXT :RETURN MENU :EXIT MENU EXIT
