Motion MCW with MediaWave Computer
– Installation and Assembly Procedure
1
Document No. 002-15-0010
Motion Proprietary & Confidential
Copyright © 2009 Motion Computing, Inc. as an unpublished work
1.
Base with power supply shroud installed
1.1
Remove the plastic Shroud that covers the power supply
Tip: Setting the wheel locks will help hold the Base assembly in place.
2.
Column assembly
