Motion MCW with MediaWave Computer
– Installation and Assembly Procedure
14
Document No. 002-15-0010
Motion Proprietary & Confidential
Copyright © 2009 Motion Computing, Inc. as an unpublished work
7.1
Place the Mounting plate with the back side facing up, and set the Battery
Gauge plate over the fixed mount screws.
7.2
Attach the Battery Gauge housing to the Mounting plate.
