TECHNICAL DATA
SC9000 MAIN UNIT
Supply:
230VAC 50 Hz, 4 x AA back-up
battery - 24-hour stand-by.
Supply current : < 80 mA capacitive
Signal transmission: > 5Vpp in 5 Ohm at 120 kHz ± 1 kHz
X-10 transmission: 1 pulse burst at 0˚, 60˚ and 120˚
Sends X-10 Key codes: On, Off.
RF receiver frequency:
433.92 MHz
Certification: TBR21 approved telephone selector
Integrated siren: 95 dB (A)
Capacity: Up to and incl.: 30 sensors
(door/ window, motion sensors
and/or broken glass sensors)
2 wired inputs and 16 remote controls.
Memory: 6 telephone numbers, (non-volatile)
each max. 16 digits
Control panel: For control of 16 zones and/or macros.
Ambient temperature: - 10° C to + 50° C (operation)
- 20° C to + 70° C (storage)
Dimensions: 220x140x40mm
MOTION DETECTOR MS90
Power :
2x AA battery
RF Range: Up to 100m free field,
up to 30m through walls and ceilings
PIR range: 180º - 6 meter,
in a straight line - 12 meter
Dimensions: 76x100x42mm
Frequency: 433.92
MHz
DOOR/WINDOW SENSOR DS90
Power :
2x AAA battery
Range: Up to 100m free field,
up to 30m through walls and ceilings
Dimensions: 44x86x20mm
Frequency: 433.92
MHz
KR21E KEY CHAIN REMOTE
Power :
2x CR2016 3V Lithium battery
Range: Up to 100m free field,
up to 30m through walls and ceilings
Dimensions: 38x57x12mm
Frequency: 433.92
MHz
Standard for TotalGuard, optional for SafeGuard:
COMFORT REMOTE CONTROL SH624
Power :
4x AAA battery
Range: Up to 100m free field,
up to 30m through walls and ceilings
Dimensions: 123x22x70mm
Frequency: 433.92
MHz
LM12 LAMP MODULE
Supply voltage:
230V ±10% 50 Hz
Supply current : < 20 mA capacitive
Making capacity: 40W to 300W
(normal light bulbs only)
Dimmer Speed: 4.4s from 100% to 0% ±0.2s
Signal sensitivity: 15 mVpp min 50 mVpp max at
120 kHz
Input impedance: > 55 Ohm (L - N) at 120 kHz
Ambient temperature: -10° C to + 50° C (operation)
-20° C to + 70° C (storage)
Dimensions: 52x122x33mm (without plug)
