14
SETTING THE IR CHANNEL ON THE MATRIX
1. Press the Input -, Input + and Output - buttons simultaneously.
2. The Main LCD Display will show the following
Use the Input + and Input - buttons to switch between OFF and ON states. Use
the table below to set the correct IR channel.
It is important that the IR setting that is selected match the DIP switch settings
on the IR remote. For example, if both DIP switches on the IR remote are set
to the down position (channel 0), the IR channel for the Matrix must be set to IR
channel 0 (“IR Address : 0, 1-OFF, 2-OFF”).
IR ADDRESS REMOTE SW1 REMOTE SW2
0 OFF OFF
1 ON OFF
2 OFF ON
3 ON ON
Once the correct IR channel has been set, press the Menu button.
