Grizzly G0717 - Manual (Page 55)

Model g0717 (Mfg. since 9/10)
-53-
REF PART # DESCRIPTION REF PART # DESCRIPTION
130 PCAP07M CAP SCREW M6-1 X 30 160-5 PB02M HEX BOLT M6-1 X 12
130-1 PLW03M LOCK WASHER 6MM 161 P0717161 POWER INDICATOR LIGHT TEND
130-2 PW03M FLAT WASHER 6MM 162 P0717162 START SWITCH TEND
131 P0717131 TUNGSTEN CARBIDE BLADE GUIDE 163 P0717163 EMER STOP SWITCH KEDU HY57B
132 PB126M HEX BOLT M8-1.25 X 40 164 P0717164 PUMP SWITCH TEND
133 PLW04M LOCK WASHER 8MM 165 P0717165 SPEED CONTROL VALVE
133-1 PW01M FLAT WASHER 8MM 166 P0717166 CONNECTION TUBE
134 P0717134 ADJUSTABLE BRACKET 166-1 P0717166-1 HOSE 5/16 X 15-3/4"
135 P0717135 SCALE 166-2 P0717166-2 HOSE 5/16 X 37"
135-1 PRIV013M STEEL FLUTED RIVET 2.5 X 4MM 168 P0717168 CONTROL BOX
136 PCAP64M CAP SCREW M10-1.5 X 25 169 P0717169 CONTROL PANEL
137 P0717137 SLIDE 169-1 P0717169-1 HYRAULIC MICRO-ADJUST VALVE
138 P0717138 LEFT BLADE BRACKET 169-2 P0717169-2 ON/OFF SWITCH
140 PB31M HEX BOLT M10-1.5 X 40 170 PS05M PHLP HD SCR M5-.8 X 8
140-1 PW04M FLAT WASHER 10MM 172 P0717172 HANDLE M12-1.75 X 30
141 P0717141 BLOCK 173 PN09M HEX NUT M12-1.75
142 P0717142 LOCK KNOB 3/8-16 X 2 174 PSS08M SET SCREW M4-.7 X 5
143 PSS16M SET SCREW M8-1.25 X 10 174-1 P0717174-1 HINGE PIN
144 P0717144 RIGHT BLADE BRACKET 175 PS09M PHLP HD SCR M5-.8 X 10
145 PB02M HEX BOLT M6-1 X 12 176 P0717176 INDICATOR SCALE
145-1 PLW03M LOCK WASHER 6MM 177 P0717177 SLIDE BRACKET
146 PW03M FLAT WASHER 6MM 178 P0717178 TENSION SHAFT
147 P0717147 WIRE BRUSH 179 PK20M KEY 5 X 5 X 15
148 P0717148 BUSHING 180 P0717180 HANDWHEEL
149 P0717149 RIGHT GUIDE BRACKET 181 P0717181 CONICAL SPRING 22 X 45 X 6MM
150 P0717150 BRUSH BRACKET 182 P0717182 SPACER 22MM
151 PB02M HEX BOLT M6-1 X 12 183 P0717183 TENSION INDICATOR
152 PLW03M LOCK WASHER 6MM 184 P51104 THRUST BEARING 51104
153 PW03M FLAT WASHER 6MM 187 P0717187 BLADE WHEEL GUIDE
155 PN09M HEX NUT M12-1.75 188 PSS02 SET SCREW 5/16-18 X 3/8
155-1 PB27M HEX BOLT M12-1.75 X 30 189 P0717189 EXTENSION CYLINDER
155-2 PLW05M LOCK WASHER 12MM 190 P0717190 BLADE WHEEL SHAFT
155-3 PW06M FLAT WASHER 12MM 191 PN13M HEX NUT M16-2
156 P0717156 SAW BOW STOP M12-1.75 X 50 191-1 PSS03M SET SCREW M6-1 X 8
157 P0717157 BLADE GUARD 192 PCAP14M CAP SCREW M8-1.25 X 20
158 P0717158 KNOB 1/4-20 X 3/8" 193 PCAP129M CAP SCREW M12-1.75 X 20
159 P0717159 HOSE 8 X 700MM 193-1 P0717193-1 AXLE WASHER
160 P0717160 ADJUSTING VALVE 194 P0717194 GIB
160-1 P0717160-1 HOSE 8 X 320MM 195 P0717195 WHEEL ALIGNMENT BOLT M16-2 X 30
160-2 P0717160-2 HOSE CLAMP 14MM 196 PB34M HEX BOLT M10-1.5 X 60
160-3 P0717160-3 VALVE BRACKET 197 PLW06M LOCK WASHER 10MM
160-4 PLW03M LOCK WASHER 6MM
saw Bow parts List (continued)
