Identification – Grizzly G0717 User Manual
Page 5
Model g0717 (Mfg. since 9/10)
-3-
figure 3. identification.
a. Blade tension handwheel
B. saw lift handle
C. upper Wheel Cover
D. saw Bow
E. Control panel
f. lower Wheel Cover
G. Motor
h. Work stop rod
i. Chip tray
identification
a
B
C
d
e
F
g
h
i
J
K
l
M
n
o
p
Q
J. Work stop
K. leveling Foot
L. Vise handwheel
M. Vise Quick adjustment
n. Blade guard
O. Blade
p. Vise
Q. Blade guide assemblies
