Grandstream Networks GXW410X - Manual (Page 11)

F
EATURES
The GXW410x is a next generation IP voice and video gateway that features full interoperability with
leading IP­PBXs, Soft­switches and SIP platforms. The GXW410x series gateways offer superb voice and
video quality, traditional telephony functionality, simple configuration, feature­rich functionality and an
additional video port that enables the gateway to act as a video surveillance gateway.
S
OFTWARE
F
EATURES
O
VERVIEW
• 4 and 8 FXO port media gateways
• Video surveillance port
• External power supply
• Two RJ­45 ports (switched or routed)
• TFTP and HTTP firmware upgrade support
• Multiple SIP accounts, multiple SIP profiles (choice of 3 profiles per account)
• Supports Audio Codecs: G711U/A, G723, G729A/B and GSM
• Supports Video Codecs: H.264
• G.168 – echo cancellation
• Flexible DTMF transmission: In Audio, RFC2833, SIP Info or any combination of the 3
• Selectable, multiple LBR coders per channel
• T.38 compliant
H
ARDWARE
S
PECIFICATION
T
ABLE
4: H
ARDWARE
S
PECIFICATION OF
GXW410
X
LAN interface 2xRJ45 10/100Mbps
LED 8 LEDs (GREEN)
Universal Switching
Power Adapter Input: 100­240V AC, 50/60Hz, 0.5A Max
Output: 12V DC, 1.25A
UL certified
Dimension 225mm (L) x 172mm (W) x 42mm (H)
Weight 0.29 lbs (3.5 oz)
Temperature 32~104°F
0~40°C
Humidity 10% ­ 90% (non­condensing)
Compliance FCC, CE
