model g0596-99 (mfg. since 3/06)
-11-
Dust Collection
the model g0596-99 features a dust port at the
rear of the grinding wheel. if a dust collection sys-
tem is not attached, both ports have spark deflec-
tors that direct sparks downward.
To connect a dust collection hose:
1. remove the spark deflector.
2. Fit the dust hose over the dust port, as shown
in figure 4, and secure in place with a hose
clamp.
3. tug the hose to make sure it does not come
off. Note: A tight fit is necessary for proper
performance.
Test Run
the test run ensures that the grinder and grinder
wheels were not damaged during shipping.
To test run the grinder:
1. review and understand all grinder safety
information.
2. remove the wheels and closely inspect the
overall conditions. Follow this by performing
a "ring test" (see
Wheel Inspection on
page 15 and Wheel Replacement on page
16).
3. plug the grinder into the power source.
4. put on safety glasses and face shield.
5. stand to the side of the line of the wheels
rotation, turn the grinder ON, and allow it to
run a least one minute, before standing in
front of it.
—the grinder should run smoothly.
—grinding wheels should run true without
noticeable vibration.
—if there is an obvious problem with the way
the grinder is running, turn it OFF immedi-
ately and troubleshoot the problem, using
the troubleshooting table on
page 18. do
Not operate the grinder until it is fixed.
figure 4. dust port.
spark deflector
dust port
fIRE AND EXpLOSION HAzARD! DO NOT
attach dust ports to a dust collection system
designed or used for wood dust collection.
DO NOT operate the Model G0596-99 without
an adequate dust collection system. This
grinder creates substantial amounts of dust
while operating. failure to use a dust collec-
tion system can result in short and long-term
respiratory illness.
