Grizzly Disc G0724 - Manual (Page 30)

-28-
Model g0724 (Mfg. since 09/11)
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0724001 MITER GAUGE KNOB M6-1 X 20 29-1 P0724029-1 MOTOR COVER
2 PW03M FLAT WASHER 6MM 29-2 P0724029-2 MOTOR FAN
3 P0724003 MITER GAUGE BODY 29-3 P0724029-3 R CAPACITOR 25M 250V 1-3/8 X 2-1/2
4 PS17M PHLP HD SCR M4-.7 X 6 29-4 P0724029-4 CAPACITOR COVER
5 PW05M FLAT WASHER 4MM 30 PB02M HEX BOLT M6-1 X 12
6 P0724006 POINTER 31 PW03M FLAT WASHER 6MM
7 P0724007 MITER BAR 32 P0724032 BASE
9 P0724009 POWER CORD 18G 3W 72"L 5-15 33 P0724033 POINTER
10 P0724010 STRAIN RELIEF STR SNAP-IN 5/8" 34 PW02M FLAT WASHER 5MM
11 PTLW02M EXT TOOTH WASHER 5MM 35 PS19M PHLP HD SCR M5-.8 X 6
12 PS05M PHLP HD SCR M5-.8 X 8 36 P0724036 BUSHING
13 P0724013 MOTOR HOUSING COVER 38 PCAP27M CAP SCREW M6-1 X 14
14 PR18M EXT RETAINING RING 17MM 39 P0724039 TABLE
15 G8988 PADDLE SWITCH 40 PW01M FLAT WASHER 8MM
16 P0724016 DISC HOUSING 41 P0724041 LOCK LEVER M8-1.25 X 15
17 PCAP26M CAP SCREW M6-1 X 12 42 PN01M HEX NUT M6-1
18 PSS31M SET SCREW M5-.8 X 8 43 P0724043 BAG CLAMP
19 P0724019 FAN 44 P0724044 SOLID PIN 4.5 X 20MM
20 P0724020 DUST CHUTE 45 P0724045 CLAMP HANDLE
21 PSS16M SET SCREW M8-1.25 X 10 46 P0724046 SWING BOLT M6 1 X 50
22 P0724022 DISC 12" ALUMINUM 47 P0724047 DUST COLLECTION BAG
23 P0724023 ABRASIVE DISC 12" PSA 100G 48 P0724048 FOOT RIGHT
24 P0724024 DISC COVER 49 P0724049 FOOT LEFT
25 PS08M PHLP HD SCR M5-.8 X 12 50 PHTEK3M TAP SCREW M3.5 X 8
26 P0724026 TAP SCREW M4.8 X 12 51 P0724051 PLASTIC PLUG
27 PCAP50M CAP SCREW M5-.8 X 10 52 P0724052 PILOT CAP SCREW M5-.8 X 8, 4 X 5 HEAD
28 PK12M KEY 5 X 5 X 30 53 PAW04M HEX WRENCH 4MM
29 P0724029 MOTOR 1/3HP 120V 1725RPM 54 PAW05M HEX WRENCH 5MM
Main parts List
