H6246 wiring diagram – Grizzly H6246 User Manual
Page 29
H6246 Meat Cutting Bandsaw
-27-
H6246 Wiring Diagram
110 VOLT
MOTOR WIRES
BLACK
BLUE
RED
WHITE
GREEN(GROUND)
TO 110 VOLT
POWER SUPPLY
WHITE
NOTE—The wires from the power
supply, besides the green ground wire,
are interchangable, therefore colors
are not specified.
Disconnect power before
performing any electrical
service. Electricity presents
serious shock hazards that
will result in severe personal
injury and even death!
H6246
110V Single-Phase
