G1140 Edge Sander -13-
Figure 14. Installing the auxiliary table.
Auxiliary Table
Figure 15. Dust hood mounted in place.
Dust Hood
Bolt the dust hood on using the hex bolts already
threaded in place. See Figure 15.
Slide the auxiliary table into place as pictured in
Figure 14. Tighten the two thumb screws when
table is at desired working height. It is not nec-
essary to have the auxiliary table mounted at all
times and can be installed only when needed.
Operating this equipment has the potential
for respiratory damage to occur due to the
level of airborne dust it produces. Always
use a dust collection system AND wear a
dust mask or respirator to avoid breathing
wood dust. Serious personal injury may
occur.
