Grandstream Networks, Inc. GXP User Manual Page 25 of 39
Firmware 1.1.6.46 Last Updated: 03/2008
Table 13: Device Configuration - Status
MAC Address The device ID, in HEXADECIMAL format.
IP Address This field shows IP address of GXP
Product Model This field contains the product model information.
Part Number This field contains the product part number
Software Version • Program: This is the main software (firmware) release number, always used to
identify the software (firmware) system of the phone.
• Boot: Booting code version number
System Up Time This field shows system up time since the last reboot.
System Time This field shows the current time on the phone system.
Registered
Indicates whether accounts are registered to the related SIP server(s). GXP can
support four unique SIP profiles.
PPPoE Link Up Indicates whether the PPPoE connection is enabled (connected to a modem).
Table 14: Device Configuration – Basic Settings
End User
Password This contains the password to access the Web Configuration Menu. This field is
case sensitive with a maximum length of 25 characters.
IP Address There GXP operates in two modes:
1. DHCP mode: all the field values for the Static IP mode are not used (even
though they are still saved in the Flash memory.) The GXP acquires its IP
address from the first DHCP server it discovers on its LAN. The DHCP
option is reserved for NAT router mode. To use the PPPoE feature, set the
PPPoE account settings. The GXP establishes a PPPoE session if any of
the PPPoE fields is set.
2. Static IP mode: configure all of the following fields: IP address, Subnet
Mask, Default Router IP address, DNS Server 1 (primary), DNS Server 2
(secondary). These fields are set to zero by default.
Multi Purpose Key X These options are used to assign a function to the corresponding multi purpose key.
Options available are:
1. “Speed Dial”.
2. “BLF” (Busy Lamp Field). This option has to be supported on the PBX and it
indicates the status of the extension. The three possible states are idle
(green), busy (red), ringing (blinking red).
3. “Presence Watcher”. This option has to be supported by a presence server
and it is tied to the “Do not disturb” status of the phone.
4. “Eventlist BLF”. This option is similar to the BLF option but in this case the
PBX collects the information from the phones and sends it out in one single
notify message.
Each function is connected to one of the accounts and has a target user ID.
Time Zone This parameter controls the date/time display according to the specified time zone.
