Grandstream Networks, Inc.

GXP User Manual

Page 21 of 39

Firmware 1.1.6.46

Last Updated: 03/2008

Configuration Guide

The GXP can be configured in two ways. Firstly, using the Key Pad Configuration Menu on the phone; secondly,
through embedded web-configuration menu.

C

ONFIGURATION

V

IA

K

EYPAD

To enter the MENU, press the round button. Navigate the menu by using the arrow keys: up/down and left/right.
Press the OK button to confirm a menu selection, delete an entry by pressing the MUTE/DEL button. The phone
automatically exits MENU mode with an incoming call, the phone is off-hook or the MENU mode if left idle for 20
seconds.

Press the MENU button to enter the key the Key Pad Menu. The menu options available are listed in table 8.

Table 12: Key Pad Configuration Menu

Call History

Displays histories of incoming, dialed and missed calls.

Status

Displays the network status, account statuses, software version and
MAC-address of the phone.

Phone Book

Displays the phonebook

LDAP Directory

Displays the LDAP directory

Instant Messages

Goes to voice messages

Direct IP call

Displays the IP-call options menu

Preference

Press Menu button to enter this sub menu including

• “Do NOT Disturb

DND (Do NOT Disturb) function could be turned on or off in
the “DO NOT Disturb” menu.

Ring Tone

Choose different ring tones in the “Ring Tone” menu.

Ring Volume

Press Menu button to hear the selected ring volume, press

or to hear and adjust the ring tone volume.

LCD Contrast

LCD Brightness

Download SCR XML

The phone will download the custom idle screen (if available)

Erase Custom SCR

Custom idle screen will be erased and will be replaced with
default Grandstream logo.

Display Language

You can choose English, Chinese or Secondary Language

Press

Menu

button to choose the menu item.

Press

‘←’ to return to the main menu.
