2. Attach a Wheel (86) to the Base (85) with an
M10 x 50mm Bolt (27) and an M10 Nut (33). Do
not overtighten the Nut; the Wheel must turn
freely.
85
27
33
2
86
3. Identify the Right Upright (78) and the Right
Upright Spacer (80), which are marked with
stickers. Insert the Upright Wire (77) through the
Right Upright Spacer as shown. Then, set the
Right Upright Spacer on the Base (85).
Have a second person hold the Right Upright
(78) near the Base (85). See the inset drawing.
Tie the wire tie in the Right Upright securely
around the end of the Upright Wire (77). Then,
pull the other end of the wire tie until the Upright
Wire is routed completely through the Right
Upright.
85
77
78
80
77
3
Wire
Tie
78
77
Wire Tie
1. Make sure that the power cord is unplugged.
With the help of a second person, carefully tip
the treadmill onto its left side. Partially fold the
Frame (48) so that the treadmill is more stable;
do not fully fold the Frame yet.
Cut the shipping tie securing the Upright Wire
(77) to the Base (85). Next, locate the plastic tie
in the indicated hole in the Base, and use the
plastic tie to pull the Upright Wire out of the hole.
Attach a Base Pad (81) to the Base (85) in the
location shown with an M4.2 x 25mm Tek Screw
(2) and a Base Pad Spacer (64). Then, attach
another Base Pad (81) with only an M4.2 x
25mm Tek Screw (2).
85
2
48
81
1
81 2
77 Hole
64
