Grandstream Networks, Inc.
HT–496 User Manual
Page 15 of 33
Firmware 1.0.3.64
Last Updated: 1/2007
Configuration Guide
C
ONFIGURING
HT–496
THROUGH
V
OICE
P
ROMPT
DHCP
M
ODE
Select voice menu option 01 to enable HT–496 to use DHCP.
STATIC
IP
M
ODE
Select voice menu option 01 to enable HT–496 to use STATIC IP mode, then use option 02, 03, 04, 05 to
set up IP address, Subnet Mask, Gateway and DNS server respectively.
F
IRMWARE
S
ERVER
IP
A
DDRESS
Select voice menu option 13 to configure the IP address of the firmware server.
C
ONFIGURATION
S
ERVER
IP
A
DDRESS
Select voice menu option 14 to configure the IP address of the configuration server.
U
PGRADE
P
ROTOCOL
Select voice menu option 15 to choose firmware and configuration upgrade protocol. User can choose
between TFTP and HTTP.
F
IRMWARE
U
PGRADE
M
ODE
Select voice menu option 17 to choose firmware upgrade mode among the following three options:
1) always check, 2) check when pre/suffix changes, and 3) never upgrade
WAN
P
ORT
W
EB
A
CCESS
Select voice menu option 12 to enable WAN Port Wed Access of the device configuration pages.
C
ONFIGURING
HT–496
WITH
W
EB
B
ROWSER
HT–496 has an embedded Web server that will respond to HTTP GET/POST requests. It also has
embedded HTML pages that allow users to configure the HT–496 through a Web browser such as
Microsoft’s IE and AOL’s Netscape.
A
CCESS THE
W
EB
C
ONFIGURATION
M
ENU
The HT–496 HTML configuration menu can be accessed via LAN or WAN port:
F
ROM THE
LAN
PORT
:
1. Directly connect a computer to the LAN port.
2. Open a command window on the computer
3. Type in “ipconfig /release”, the IP address etc. becomes 0.
4. Type in “ipconfig /renew”, the computer gets an IP address in 192.168.2.x segment by default
5. Open a web browser, type in the default gateway IP address.
http://192.168.2.1
. You will see the
login page of the device.
