Operator's Manual Fourth Edition • Third Printing
36 Z-34/22 IC Part No. 1000048
SPECIFICATIONS
Z-34/22 2WD and 4WD RT
Height, working maximum 40 ft 10 in 12.6 m
Height, platform maximum 34 ft 10 in 10.6 m
Height, stowed maximum 6 ft 9 in 2 m
Horizontal reach maximum 22 ft 3 in 6.8 m
Width 6 ft 1 in 1.8 m
Length, stowed 18 ft 7 in 5.7 m
Maximum load capacity 500 lb 227 kg
Maximum wind speed 28 mph 12.5 m/s
Wheelbase 6 ft 2 in 1.9 m
Turning radius (outside) 13 ft 6 in 4.1 m
Turning radius (inside) 5 ft 11 in 1.8 m
Ground clearance 6.5 in 16.5 cm
Turntable rotation (degrees) 355°
Turntable tailswing 0
Platform leveling self-leveling
Platform rotation (degrees) 180°
Controls 12V DC proportional
Platform dimensions, 56 in x 30 in
(length x width) 1.4 m x 76 cm
Power source Kubota G/LPG 24.5 hp
OR Kubota Diesel 26 hp
Fuel capacity 9.3 gallons 35.2 liters
AC outlet in platform standard
Hydraulic pressure, maximum 3200 psi 220.7 bar
(boom functions)
System voltage 12V
Tires size (ANSI)
Industrial
9-14.5
Rough terrain 10-16.5NHS
Tires size (CE and Australia)
Foam filled only
9-14.5
Weight See Serial Plate
(Machine weights vary with option configurations)
Airborne noise emissions 80 dB
Maximum sound level at normal operating workstations
(A-weighted)
Drive speeds, maximum,
Boom stowed 3.5 mph 5.6 km/h
40 ft/7.8 sec 12.2/7.8 sec
Boom
raised or extended
0.7 mph 1.0 km/h
2WD & 4WD models 40 ft/40 sec 12.2 m/40 sec
Maximum slope rating, stowed position, 4WD
Counterweight uphill 45% 24°
Counterweight downhill 40% 22°
Side slope 25% 14°
Note: Slope rating is subject to ground conditions and
adequate traction.
Floor Loading Information
Tire load, maximum 5300 lbs 2404 kg
Tire contact pressure (per tire) 45 psi 3.16 kg/cm 2
310 kPa
Occupied floor pressure 221 psf 10.58 kPa
1079 kg/m 2
Note: Floor loading information is approximate and does
not incorporate different option configurations. It should be
used only with adequate safety factors.
