DECALS
Inspection for Decals with
Symbols
Determine whether the decals on your machine
have words or symbols. Use the appropriate
inspection to verify that all decals are legible and in
place.
Part No.
Decal Description
Quantity
28158
Label - Unleaded
1
28159
Label - Diesel
1
28160
Label - LPG
1
28171
Label - No Smoking
2
28174
Label - Power to Platform, 230V
2
28235
Label - Power to Platform, 115V
2
37053
Arrow - Blue
1
37054
Arrow - Yellow
1
37055
Triangle - Blue
2
37056
Triangle - Yellow
2
40434
Label - Lanyard Anchorage
2
44779
Label - Generator (option)
1
44981
Label - Air Line to Platform
2
52968
Cosmetic - Genie Boom
1
62930
Cosmetic - Genie Z-34/22
1
62947
Cosmetic - IC Power 4 x 2
1
62948
Cosmetic - IC Power 4 x 4
1
Part No.
Decal Description
Quantity
72094
Ground Control Panel
1
72095
Platform Control Panel
1
82472
Warning - Crushing Hazard
3
82473
Caution - Compartment Access
1
82487
Label - Operating Instructions
2
82544
Danger - Electrocution Hazard
2
82548
Warning - Platform Rotate
2
82601
Danger - Maximum Load, 227 kg
1
82602
Danger - Max Manual Force, 667 N
1
82604
Danger - Max Manual Force, 400 N
1
82611
Label - Drive Enable Patch
1
97815
Label - Lower Mid-rail
1
133299
Label - Wheel Load
4
