Installation Instructions
ADVANCE PLANNING
CAUTION:
Due to excessive weight,
TWO PEOPLE ARE REQUIRED TO MOVE AND
INSTALL THIS ICEMAKER. Failure to do so can
result in back or other injury.
MISE EN GARDE :
A cause de son poids élevé, IL FAUT DEUX
PERSONNES POUR DÉPLACER ET INSTALLER
CETTE MACHINE À GLAÇONS. Le non-respect
de ces instructions peut causer des blessures
au dos ou d’autre nature.
WATER SUPPLY
A cold water supply with water pressure of between
30 and 120 psi is required to operate the icemaker.
If you have questions about your water pressure,
call a licensed, qualified plumber.
REVERSE OSMOSIS WATER SUPPLY
IMPORTANT:
The performance of the icemaker
may be affected when it is connected to a reverse
osmosis system.
• The pressure of the water supply coming out of a
reverse osmosis system going to the water inlet
valve of the icemaker needs to be between 30 and
120 psi.
• If a reverse osmosis water filtration system is
connected to your cold water supply, the water
pressure to the reverse osmosis system needs to
be a minimum of 40 to 60 psi. The reverse osmosis
system must provide 1 gal. of water per hour to
the icemaker for proper icemaker operation.
• Do not use copper tubing when the icemaker is
connected to a reverse osmosis water system.
Choose the location:
• Not designed for outdoor installation.
• The icemaker must be installed in an area
protected from elements such as wind, rain, water
spray or drip. The area should be ven ti lat ed with
temperatures above 55°F (13°C) and below 110°F
(43°C). Best results are obtained between 70°F
(21°C) and 90°F (32°C).
• The icemaker may be closed in on the top and
three sides as long as the front is un ob struct ed
for air circulation and proper op er a tion.
–Installation should be such that the icemaker
can be moved forward for ser vic ing, if necessary.
–The bottom grille on the front must be
unobstructed to provide proper air flow.
ADVANCE PLANNING (cont.)
Before you begin:
1. If a custom panel is to be installed, follow
the instructions shown on pages 10 and 11.
–Order ZIP75 (black) panel kit.
–Order the custom panel from the cabinet
manufacturer.
–Secure the custom panel onto the icemaker.
2. Determine a method of drainage. If a floor drain
is to be installed, the drain must be accurately
located. The installation of a custom door panel
will affect the drain location. See page 7 to
determine the exact location of the floor drain,
front to back, with or without a custom door
panel.
–A drain pump kit, ZPK1, is available and will not
interfere with placement of the icemaker.
3. The door swing is reversible. If desired, change
the door swing before installation.
4. Slide the icemaker into the installation location.
–Open and close the door to be sure there is no
interference.
–Check to be sure the icemaker can be moved
back into the opening, flush with adjacent
cabinetry. There should be no interference
with the floor drain.
–Check to be sure the icemaker is level. The
icemaker will not operate properly if it is not
level. See page 6.
5
