Model G0642 15-Bit Line Boring Machine
-31-
Table Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
101 P0642101 CROSS STOP PLATE 121 P0642121 CROSS FENCE SCALE LEFT
102 P0642102 MOUNTING BLOCK 122 PLW04M LOCK WASHER 8MM
103 PLN05M LOCK NUT M10-1.5 123 PSB14M CAP SCREW M8-1.25 X 20
104 P0642104 STOP PIN 124 P0642124 CROSS FENCE END PLUG RIGHT
105 PSB11M CAP SCREW M8-1.25 X 16 125 P0642125 CROSS FENCE
106 P0642106 LOCK LEVER 126 P0642126 CROSS FENCE SCALE RIGHT
107 PN03M HEX NUT M8-1.25 127 P0642127 TABLE MOUNT
108 P0642108 LONGITUDINAL STOP PLATE 128 P0642128 TABLE
109 PSS02M SET SCREW M6-1 X 6 129 PW03M FLAT WASHER 6MM
110 PW02M FLAT WASHER 5MM 130 PN01M HEX NUT M6-1
111 PS08M PHLP HD SCR M5-.8 X 12 131 P0642131 BUSHING
114 P0642114 LONGITUDINAL FENCE 132 P608 BALL BEARING 608ZZ
115 PFH03M FLAT HD SCR M6-1 X 40 133 PSB40M CAP SCREW M8-1.25 X 35
116 P0642116 LONGITUDINAL SCALE CENTER LEFT 134 P0642134 CABINET TOP
117 P0642117 FENCE CONNECTING ROD 135 PSB31M CAP SCREW M8-1.25 X 25
118 PSB24M CAP SCREW M5-.8 X 16 136 PSB58M CAP SCREW M8-1.25 X 12
119 P0642119 LONGITUDINGAL SCALE LEFT 137 PW01M FLAT WASHER 8MM
120 P0642120 CROSS FENCE END PLUG LEFT 138 P0642138 LONGITUDINAL SCALE CENTER RIGHT
