Hardware Installation
- 8 -
1-2 Product Specifications
CPU
AM3+ Socket:
- AMD AM3+ FX processors
* You must install an external graphics card if you want to install Windows XP on your
AM3+ CPU-based system.
- AMD AM3 Phenom
™
II processors/AMD Athlon
™
II processors
(Go to GIGABYTE's website for the latest CPU support list.)
Hyper Transport
Bus
2000 MT/s
Chipset
NVIDIA
®
GeForce 7025/nForce 630a
Memory
2 x 1.5V DDR3 DIMM sockets supporting up to 8 GB of system memory
* Due to Windows 32-bit operating system limitation, when more than 4 GB of physical
memory is installed, the actual memory size displayed will be less than 4 GB.
Dual channel memory architecture
Support for DDR3 1600/1333/1066/800 MHz memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
Chipset:
- 1 x D-Sub port
Audio
Realtek ALC888B/889 codec
High Definition Audio
2/4/5.1/7.1-channel
* To configure 7.1-channel audio, you have to use an HD front panel audio module
and enable the multi-channel audio feature through the audio driver.
LAN
1 x Realtek RTL8211CL chip (10/100/1000 Mbit)
Expansion Slots
1 x PCI Express x16 slot, running at x16
2 x PCI Express x1 slots
1 x PCI slot
Storage Interface
Chipset:
- 4 x SATA 3Gb/s connectors supporting up to 4 SATA 3Gb/s devices
- Support for RAID 0, RAID 1, RAID 5, RAID 10, and JBOD
USB
Chipset:
- Up to 10 USB 2.0/1.1 ports (4 ports on the back panel, 6 ports available
through the internal USB headers)
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
4 x SATA 3Gb/s connectors
1 x CPU fan header
1 x system fan header
1 x front panel header
1 x front panel audio header
3 x USB 2.0/1.1 headers
1 x parallel port connector
1 x clearing CMOS jumper
