- 23 - BIOS Setup
Precharge Time
Options are: Auto (default), 4T~7T.
Row Cycle Time
Options are: Auto (default), 11T~42T.
RAS to RAS Delay
Options are: Auto (default), 4T~7T.
CKE Power Down Mode
Determines whether to set the memory to power down mode when the CKE pin is closed. (Default: Dis-
abled)
CKE Power Down Control
Allows you to select a CKE power down mode. Options are per Channel (Default), per CS.
DDR3 Voltage Control
Allows you to set the memory voltage.
Normal Supplies the memory voltage as required. (Default)
+0.1V ~ +0.7V The adjustable range is from +0.1V to +0.7V.
Note: Increasing memory voltage may result in damage to the memory or reduce the useful life of the
memory.
CPU NB VID Control
Allows you to set the CPU Northbridge VID voltage. Auto sets the CPU Northbridge VID voltage as re-
quired. The adjustable range is dependent on the CPU being installed. (Default: Normal)
Note: Increasing CPU voltage may result in damage to your CPU or reduce the useful life of the CPU.
CPU Voltage Control
Allows you to set the CPU voltage. Auto sets the CPU voltage as required. The adjustable range is de-
pendent on the CPU being installed. (Default: Normal)
Note: Increasing CPU voltage may result in damage to your CPU or reduce the useful life of the CPU.
Normal CPU Vcore
Displays the normal operating voltage of your CPU.
2-4 Standard CMOS Features
CMOS Setup Utility-Copyright (C) 1984-2010 Award Software
Standard CMOS Features
Date (mm:dd:yy) Fri, Dec. 17 2010
Time (hh:mm:ss) 22:31:24
 IDE Channel 0 Master [None]
 IDE Channel 1 Master [None]
 IDE Channel 2 Master [None]
 IDE Channel 3 Master [None]
Halt On [All, But Keyboard]
Base Memory 640K
Extended Memory 1790M
 : Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level 
