Know your product
Before using the tool, familiarise
yourself with all the operating features
and safety requirements.
Use the tool and accessories only for
the applications intended. All other
applications are expressly ruled out.
1. On/off switch / variable speed dial
2. Laser light on/off switch
3. LED light on/off switch
4. Laser aperture
5. Laser line alignment knob
6. Sawdust blower
7. LED light
8. Drop foot
9. Drop foot locking knob
10. Table
11. Table insert
12. Blade tension lever
13. Blade adapters
14. Blade adapter knobs
15. Blade
16. Bevel adjustment scale
17. Table lock knob
18. Table adjustment knob
19. Blade storage compartment
1 2 3 12 13 14
5
8
9
10
11
16
17
19
15
13 14
18
4
6
7
