55
ITEM PART
NO. QTY. DESCRIPTION
58
022097
3
WASHER LOCK M6-1/4
59
0E9561
1
INTAKE ADAPTER
60
0E9472
1
GASKET, AIRBOX TO CARB/MIXER
61
0E9471
1
GASKET, MANIFOLD TO CARB/MIXER
62
078643B
4
BOLT, CARB MOUNT M6 – 1.0 X 85
63
0D9784
1
NUT HEX LOCK M3 – 0.5
64
0E9584
1
ASSY, CONTROLLER
65
0D6342
1
BALL STUD, 10 MM
66
0E9587
1
ASSY, THROTTLE ROD
67
0C9997
1
GUARD, FAN
68
0E9319
2
GASKET INTAKE
69
0E9597
1
BREATHER HOSE
70
040976
4
SCREW SHC M8 – 1.25 X 20 G12.9
71
022129
2
WASHER LOCK M8 – 5/16
72
061906
2
SCREW HHC M8 – 1.25 X 85
73
0E9323
1
STARTER MOTOR
74
0E9507
6
SCREW HHFC M8 – 1.25 X 14
75
0E9362
2
LIFTING HOOK
76
0E9337
1
WRAPPER OUTER CYLINDER 1
77
0E9339
1
WRAPPER INNER CYLINDER 1
78
0E9402
1
TUBE, DIPSTICK
79
0F2664H
1
ASSY, DIPSTICK /TEXT
80
0E9336F
1
BLOWER HOUSING
81
0D6147
6
SCREW HHFC M6-1.0 X 10 G8.8
82
0E5139
3
SCREW HHFC M6-1.0 X 8 G8.8
83
0E9432
1
WRAPPER INNER CYLINDER 2
84
0E9338
1
WRAPPER OUTER CYLINDER 2
85
0E9370
1
GASKET, OIL FILTER ADAPTER
86
0E9505A
1
ASSY, DIRECT OIL COOLER ADAPTER
87
0F5458
2
SCREW PLASTITE HI-LOW #10X3/8
ITEM PART
NO. QTY. DESCRIPTION
88
045757
3
SCREW HHC M6 – 1.0 X 25
89
070185B
1
OIL FILTER
90
094090
1
THERMAL SWITCH
91
0F2094
2
SCREW PPHM M3-0.5 X 6 SEMS
92
0D3083
1
ASSEMBLY, OIL DRAIN HOSE
93
0A8584
1
OIL PRESSURE SWITCH
94
082774
1
KEY, WOODRUFF 4 X 19D
95
0E7209
1
ASSY, GROUNDING WIRE
96
0E9514B
1
ASSY IGNITION COIL CYLINDER 1
0E9514C
1
ASSY IGNITION COIL CYLINDER 2
97
026850
4
WASHER SHAKEPROOF EXT 1/4
98
0E9443
1
ASSY, MIXER DUAL FUEL
99
0F6301
4
CLAMP, HOSE OETIKER 16.5MM
100
0G0286
1
HOSE 3/8”ID X 6” SAE J30R9
101
0G0479
1
HOSE 3/8”ID X 7.25 SAE J30R9
102
0E9340
1
BACKING PLATE
103
0E9525C
1
ASSY, FLYWHEEL & RING GEAR
104
0E9486
1
FAN, FLYWHEEL, 20 FIN, 218.8 OD
105
0A5992
2
WASHER LOCK INT M8
106
048571
2
SCREW HHC M8 – 1.25 X 10
107
067890
1
NUT HEX M20 – 1.5
108
067198N
1
WASHER BELV – 20 X 2.2
109
0C3032
1
PLATE, FAN
110
0E4997
1
ASSY, GROUND WIRE CONNECTOR
111
0E9406
1
OIL COOLER
112
0G1705
14
SCREW HHFC M6 – 1.0 X 14
113
0E9450
1
CENTER BAFFLE
114
0E9376
1
INTAKE MANIFOLD
115
0E9550
1
FRONT COVER
Section 9 — Exploded Views and Parts Lists
Air-cooled Generators
10kW, GT-530 Engine – Drawing No. 0F9429-C - Part 2
