Page 47
45
ITEM PART
NO. QTY. DESCRIPTION
1
0E7886A
1
CIRCUIT BREAKER 30A X 2P 240V (7KW)
0E7886D
1
CIRCUIT BREAKER 45A X 2P 240V (10KW)
0E7886K
1
CIRCUIT BREAKER 55A X 2P 240V (13KW)
0E7886J
1
CIRCUIT BREAKER 65A X 2P 240V (16KW)
2
0A1801
1
ASSEMBLY, BATTERY CHARGER ENGINE
3
0F9719
1
ASSEMBLY, POTTED REGULATOR
4
0C2174
1
RELAY, 12V 25A SPST (NON 7KW)
5
075210A
1
BLOCK
TERMINAL
1
POSITION
6
038750
1
SCREW HHC M6-1.0 x 30mm
7
0F8992
1
ASSEMBLY, HOME STANDBY CONTROLLER
0F1504
1
ASSEMBLY, HOME STANDBY CONTROLLER (7KW)
8
032300
1
HOLDER,
FUSE
9
022676
1
FUSE, 15 AMP X AGC15
10
0E4494
1
SWITCH, ROCKER DPDT ON-OFF-ON
11
0E7890
1
CIRCUIT BREAKER MOUNTING BRACKET
12
023484E
1
SNAP
BUSHING
13
075476
4
SCREW PPHM M4-0.7 x 16mm
14
043182
2
M3 LOCK WASHER (NON 7KW)
15
0E6480
6
NUT HEX LOCK M4-0.7 NYLON INSERT
16
0D4804A
1
CURRENT TRANSFORMER, IDLE CONTROL (NON 7KW)
17
0C1085
12
SCREW PPHM M3-0.5 x 8mm
0C1085
8
SCREW PPHM M3-0.5 x 8mm (7KW)
18
058000H
2
M3-0.5 TRIC NUT (NON 7KW)
19
023897
2
WASHER FLAT #10
20
0F8040
1
CONTROL,
PANEL
BOTTOM
0F9282
1
CONTROL, PANEL BOTTOM (7KW)
21
075235
4
SCREW HHC M5-0.8 x 30mm
22
0E3928
1
SWITCH,
SPST
23
0D9784
4
NUT HEX LOCK M3-0.5 NYLON INSERT
0D9784
2
NUT HEX LOCK M3-0.5 NYLON INSERT (7KW)
24
0D8502
1
NEUTRAL
BLOCK
25
031879
4
WASHER FLAT #4
031879
2
WASHER FLAT #4 (7KW)
26
0F5433
1
HARNESS, CONTROL PANEL WIRE (NOT SHOWN)
0F5437
1
HARNESS, CONTROL PANEL WIRE (NOT SHOWN) (7KW)
27
074908
4
SCREW HHTT, M5-0.8 x 10 BP
28
049813
1
NUT HEX M6-1.0
29
082025
6
NUT HEX LOCK M5-0.8 NYLON INSERT
30
0G0627
1
XFMR 240/16V 1VA&56VA W/PTC
31
022507
2
SCREW HHC 1/4”-20 x 1/2”
32
022097
3
WASHER LOCK M6-1/4”
33
046689
1
TERMINAL STRIP 4 POSITION
34
063617
1
RELAY PANEL 12VDC DPDT 10A 240VAC
35
075475
2
SCREW PPHM M4-0.7 x 10mm
36
043180
2
WASHER FLAT M4
37
0F8041
1
COVER, CONTROL PANEL COMPONENT
0F9283
1
COVER, CONTROL PANEL COMPONENT (7KW)
38
045770
2
SCREW HHC M5-0.8 x10mm
39
0E7866
1
COVER,
CONTROL
PANEL
0E7867
1
COVER, CONTROL PANEL (7KW)
40
0D3700
8
NUT FLANGE M6-1.0 NYLOK
41
0G0400
1
WIRE
ASSEMBLY,
GROUND
42
0E2874
1
SCREW HHTR 1/4"-20 X 3/4"
43
0A1658
2
WASHER LOCK SPECIAL 1/4”
44
022473
4
WASHER FLAT 1/4”-M6
Section 9 — Exploded Views and Parts Lists
Air-cooled Generators
Control Panel – Drawing No. 0F9695-B
