G1021Z 15" Planer -35-
Clean and lubricate the chain sprockets as need-
ed. The gearbox oil should be checked before the
first use. It is full when oil begins dribbling out of
the fill hole. Oil should be replaced yearly. Use
80W-90 gear oil in normal situations. Use 50W
motor oil for unheated, winter shops. See
Adjustment Section.
The lead screws and columns should be wiped of
any grease and dust build up once a week. They
should be relubricated with light machine oil. See
Figure 42.
Figure 42. Lead Screw inside of column.
Lead Screw
Column
