25
Installation Instructions
REMOVE THE FREEZER DOOR
(cont.)
As one person slowly lifts the freezer door
up and off the bottom hinge, the second
person should carefully guide the water
line and power line (harness) through the
bottom hinge.
Set the door on a non-scratching surface
with the inside up.
7
D
E
90°
REMOVE THE REFRIGERATOR
DOOR
Remove the refrigerator door top hinge
cover (if equipped) by either squeezing it
and pulling it up or by prying it off with
a plastic putty knife.
8
A
REMOVE THE REFRIGERATOR
DOOR (cont.)
Remove the two 5/16
″ or 1/8″ hex head
screws, then lift the hinge straight up to
free the hinge pin.
Open the refrigerator door to 90.°
8
B
C
5/16 ″ or 1/8″ hex head
90°
