12
3.5 • Place five coals on the front of the fuel bed so they rest
on the front coal effect and lean against the vertical fingers,
Diagram 9
AR0902
9
3.6 • Place the remaining four coals between the two rows of
coals
• Rotate the coals to ensure they are secure on the fuel
bed, Diagram 10
AR0903
10
3.7 • Close the door and tighten the bolt and domed nut
NOTE: ENSURE THAT THE COALS ARE POSITIONED, AS
DETAILED ABOVE. ONLY USE THE CORRECT AMOUNT
OF COALS, AS SPECIFIED IN THE DIAGRAMS
4. LIGHTING
4.1 Full instructions are given in the User Section of this manual
INSTALLATION INSTRUCTIONS
INSTALLATION
