July 2004 figure rev description – Genie 106730 User Manual

Page 31

Welder Supplement

Part No. 106730

July 2004

Figure

Rev

Description

Genie PN

Parker PN

Description

48919

6 S5OLO-S

BRANCH TEE,STRAIGHT THREAD TO ORFS

48920

6 V5OLO-S

ELBOW,45º,STRAIGHT THREAD TO ORFS

48921

6 FLO-S

CONNECTOR,MALE PIPE TO ORFS

48922

6-6 FLO-S

CONNECTOR,MALE PIPE TO ORFS

48923

6 P5ON-S

PLUG,STRAIGHT THREAD

48925

6 WELO-S

UNION,90º BULKHEAD,ORFS

48926

6-4 C5OLO-S

ELBOW,90º,STRAIGHT THREAD TO ORFS

48927

6-4 F5OLO-S

CONNECTOR,STRAIGHT THREAD TO ORFS

48928

6-4 V5OLO-S

ELBOW,45º,STRAIGHT THREAD TO ORFS

48929

6-8 C5OLO-S

ELBOW,90º,STRAIGHT THREAD TO ORFS

48930

6-8 F5OLO-S

CONNECTOR,STRAIGHT THREAD TO ORFS

48931

6-10 F5OLO-S

CONNECTOR,STRAIGHT THREAD TO ORFS

48932

8 C5OLO-S

ELBOW,90º,STRAIGHT THREAD TO ORFS

48933

8 F5OLO-S

CONNECTOR,STRAIGHT THREAD TO ORFS

48934

8 FF5OLO-S

CONNECTOR,LONG,STRAIGHT THREAD TO ORFS

48935

8 R5OLO-S

RUN TEE,STRAIGHT THREAD

48936

8 S5OLO-S

BRANCH TEE,STRAIGHT THREAD TO ORFS

48937

8 V5OLO-S

ELBOW,45º,STRAIGHT THREAD TO ORFS

48938

8 R6LO-S

RUN TEE,SWIVEL NUT,ORFS

48939

8 S6LO-S

BRANCH TEE,SWIVEL NUT TO ORFS

48940

8 WJJLO-WLNL-S

RUN TEE, BULKHEAD,ORFS

48941

8-4 TRLO-S

REDUCER,TUBE END TO SWIVEL,ORFS

48942

8-6 C5OLO-S

ELBOW,90º,STRAIGHT THREAD TO ORFS

48943

8-6 F5OLO-S

CONNECTOR,STRAIGHT THREAD TO ORFS

48944

8-8 FLO-S

CONNECTOR,MALE PIPE TO ORFS

48945

8 FTX-S

CONNECTOR,MALE PIPE TO FLARE TUBE

48946

8-10 F5OLO-S

CONNECTOR,STRAIGHT THREAD TO ORFS

48947

8-12 C5OLO-S

ELBOW,90º,STRAIGHT THREAD TO ORFS

48948

8-12 F5OLO-S

CONNECTOR,STRAIGHT THREAD TO ORFS

48949

8-16 F5OLO-S

CONNECTOR,STRAIGHT THREAD TO ORFS

48950

10 C5OLO-S

ELBOW,90º,STRAIGHT THREAD TO ORFS

48951

10 CC5OLO-S

ELBOW,90º LONG,STRAIGHT THREAD TO ORFS

48952

10 F5OLO-S

CONNECTOR,STRAIGHT THREAD TO ORFS

48953

10 R5OLO-S

RUN TEE,STRAIGHT THREAD

48954

10 S5OLO-S

BRANCH TEE,STRAIGHT THREAD TO ORFS

48955

10 R6LO-S

RUN TEE,SWIVEL NUT,ORFS

48956

10-4 TRLO-BL-S

REDUCER,TUBE END TO SWIVEL,ORFS

48957

10-6 TRLO-BL-S

REDUCER,TUBE END TO SWIVEL,ORFS

48958

10-12 F5OLO-S

CONNECTOR,STRAIGHT THREAD TO ORFS

48959

12 C5OLO-S

ELBOW,90º,STRAIGHT THREAD TO ORFS

48960

12 F5OLO-S

CONNECTOR,STRAIGHT THREAD TO ORFS

48961

12 R5OLO-S

RUN TEE,STRAIGHT THREAD

48962

12 S5OLO-S

BRANCH TEE,STRAIGHT THREAD TO ORFS

48963

12 V5OLO-S

ELBOW,45º,STRAIGHT THREAD TO ORFS

48964

12 R6LO-S

RUN TEE,SWIVEL NUT,ORFS

48965

12 CLO-S

ELBOW,90º,MALE PIPE TO ORFS

48966

12 FLO-S

CONNECTOR,MALE PIPE TO ORFS

48967

12 JLO-S

UNION TEE,ORFS

Genie PN

Parker PN

Description

48968

12 WLO-WLNL-S

UNION,BULKHEAD,ORFS

48969

12 WJJLO-WLNL-S

RUN TEE, BULKHEAD,ORFS

48970

12 WELO-WLNL-S

UNION,90º BULKHEAD W/NUT,ORFS

48971

12 G5G5JG5-S

TEE,FEMALE STRAIGHT THREAD

48972

12 XHL6-S

ADAPTER, 37º MALE TO SWIVEL ORFS

48973

12-1/2 F5OG-S

ADAPTER,FEMALE PIPE TO STRAIGHT THREAD

48974

12-10 C5OLO-S

ELBOW,90º,STRAIGHT THREAD TO ORFS

48975

12-10 F5OLO-S

CONNECTOR,STRAIGHT THREAD TO ORFS

48976

12-16 C5OLO-S

ELBOW,90º,STRAIGHT THREAD TO ORFS

48977

12-16 F5OLO-S

CONNECTOR,STRAIGHT THREAD TO ORFS

48978

12-16 V5OLO-S

ELBOW,45º,STRAIGHT THREAD TO ORFS

48980

12-16 FLO-S

CONNECTOR,MALE PIPE TO ORFS

48983

16 C5OLO-S

ELBOW,90º,STRAIGHT THREAD TO ORFS

48984

16 F5OLO-S

CONNECTOR,STRAIGHT THREAD TO ORFS

48985

16 V5OLO-S

ELBOW,45º,STRAIGHT THREAD TO ORFS

48986

16 FLO-S

CONNECTOR,MALE PIPE TO ORFS

48988

16 CD45-S

ELBOW,45º,MALE TO FEMALE PIPE

48989

12 CD45-S

ELBOW,45º,MALE TO FEMALE PIPE

48990

8 CD45-S

ELBOW,45º,MALE TO FEMALE PIPE

48991

16-12 FLO-S

CONNECTOR,MALE PIPE TO ORFS

48992

16-12 V5OLO-S

ELBOW,45º,STRAIGHT THREAD TO ORFS

48993

XV501-12

BALL VALVE

48994

XV501-16

BALL VALVE

48995

XV510P-12

BALL VALVE

48996

XV510P-16

BALL VALVE

48997

PD341

DIAGNOSTIC NIPPLE, STRAIGHT THREAD

48998

PD 361

DIAGNOSTIC NIPPLE, STRAIGHT THREAD

48999

DT-500-MOMS-5

VALVE,CHECK

49201

10 V5OLO-S

ELBOW,45º,STRAIGHT THREAD TO ORFS

49202

1JC43-12-10

HOSE END,FEMALE SWIVEL,SEAL LOK

49203

10-8 V5OLO-S

ELBOW,45º,STRAIGHT THREAD TO ORFS

49205

6 F5OHAO-S

UNION,STRAIGHT THREAD

49207

PD34BTL

DIAGNOSTIC NIPPLE,SEAL-LOK SWIVEL

49209

8M18F870MX-S

CONNECTOR,METRIC,STRAIGHT THREAD TO

FLARE TUBE

49212

8 WGTX-WLN-S

CONNECTOR,BULKHEAD,FEMALE PIPE TO

FLARE TUBE

49213

30682-8-8

HOSE END,FEMALE SWIVEL,JIC

49216

831-8

HOSE,1/2 INCH ID

49217

33982-8-8

HOSE END,90º FEMALE SWIVEL,JIC

49219

PS-B-35

SLEEVE,NYLON,2.19" ID

49418

4-6 V5OLO-S

ELBOW,45º,STRAIGHT THREAD TO ORFS

49511

DT370-MOMS-5

VALVE,CHECK

49512

1 DD-S

ELBOW,90º,FEMALE PIPE

49513

1 FF-S

NIPPLE,PIPE

49514

10 HP5ON-S

PLUG,STRAIGHT THREAD

49515

12-16 CLO-S

ELBOW,90º,MALE PIPE TO ORFS

49517

6 HP5ON-S

PLUG,STRAIGHT THREAD

207.1

Hydraulic Hose and Fitting Cross-reference

200 • Schematics and Hose Drawings
