Part No. 106730
Welder Supplement
200 • Schematics and Hose Drawings
July 2004
205.1
Z-60/34 Hoses and Fittings
Rev A
Item
Part No.
Description
Qty.
1
94374-4830
Hose Assembly - Components:
Genie part numbers 48841,
48846 and 94358 @ 44 inches ... 1
2
48959
Fitting ............................................ 5
3
48964
Fitting ............................................ 1
4
49142-13762 Hose Assembly - Components:
Genie part numbers 48842,
48839 and 48756
@ 135 inches ............................... 1
5
89871-4848
Hose Assembly - Components:
Genie part numbers 48841,
48841 and 94358 @ 46 inches ... 1
6
48960
Fitting ............................................ 7
7
48933
Fitting ............................................ 1
8
61262
Fitting ............................................ 3
9
106665-4929 Hose Assembly - Components:
Genie part numbers 48841,
48843 and 94358 @ 46 inches ... 1
10
89581-5030
Hose Assembly - Components:
Genie part numbers 48841,
48846 and 48763 @ 47 inches ... 1
11 106665-5229 Hose Assembly - Components:
Genie part numbers 48841,
48843 and 94358 @ 49 inches ... 1
12
94374-4930
Hose Assembly - Components:
Genie part numbers 48841,
48846 and 94358 @ 46 inches ... 1
13 106666-8446 Hose Assembly - Components:
Genie part numbers 48810,
48818 and 48751 @ 82 inches ... 1
14
48875
Fitting ............................................ 1
15
48948
Fitting ............................................ 1
The length listed in the component description
is the length of the hose only.
Refer to 207.1 to cross-reference Genie part
numbers to Parker part numbers.
