200 • Schematics and Hose Drawings
July 2004
206.1
Z-80/60 Hoses and Fittings
Rev A
Item
Part No.
Description
Qty.
1
49156-3556
Hose Assembly - Components:
Genie part numbers 48849,
48853 and 48763 @ 32 inches ... 1
2
48978
Fitting ............................................ 2
3
48964
Fitting ............................................ 1
4
102355-6650 Hose Assembly - Components:
Genie part numbers 48826,
48836 and 48756 @ 64 inches ... 1
5
49156-3756
Hose Assembly - Components:
Genie part numbers 48849,
48853 and 48763 @ 34 inches ... 1
6
48963
Fitting ............................................ 6
7
48933
Fitting ............................................ 1
8
48960
Fitting ............................................ 2
9
102312-2088 Hose Assembly - Components:
Genie part numbers 48841,
102311 and 94358
@ 18 inches ................................. 1
10
94374-4030
Hose Assembly - Components:
Genie part numbers 48841,
48846 and 94358 @ 37 inches ... 1
11
94374-3730
Hose Assembly - Components:
Genie part numbers 48841,
48846 and 94358 @ 34 inches ... 1
12 102312-2388 Hose Assembly - Components:
Genie part numbers 48841,
102311 and 94358
@ 21 inches ................................. 1
13 49143-11229 Hose Assembly - Components:
Genie part numbers 48822,
48827 and 48756
@ 110 inches ............................... 1
14
48935
Fitting ............................................ 1
15
48958
Fitting ............................................ 2
The length listed in the component description
is the length of the hose only.
Refer to 207.1 to cross-reference Genie part
numbers to Parker part numbers.
