Part No. 106730
Welder Supplement
200 • Schematics and Hose Drawings
July 2004
203.1
S-40 and S-45 Hoses and Fittings
Rev A
Item
Part No.
Description
Qty.
1
102313-2726 Hose Assembly - Components:
Genie part numbers 48841,
48845 and 94358 @ 24 inches ... 1
2
48977
Fitting ............................................ 2
3
67371
Fitting ............................................ 1
4
31070-3750
Hose Assembly - Components:
Genie part numbers 48827,
48836 and 48756 @ 35 inches ... 1
5
102313-2926 Hose Assembly - Components:
Genie part numbers 48841,
48845 and 94358 @ 26 inches ... 1
6
48959
Fitting ............................................ 2
7
48933
Fitting ............................................ 1
8
48963
Fitting ............................................ 2
9
48960
Fitting ............................................ 4
10 102312-2088 Hose Assembly - Components:
Genie part numbers 48841,
102311 and
94358 @ 18 inches ...................... 1
11
94374-5030
Hose Assembly - Components:
Genie part numbers 48841,
48846 and 94358 @ 48 inches ... 2
12 102312-2388 Hose Assembly - Components:
Genie part numbers 48841,
102311 and
94358 @ 21 inches ...................... 1
13
49143-7529
Hose Assembly - Components:
Genie part numbers 48822,
48827 and 48756 @ 73 inches ... 1
14
48938
Fitting ............................................ 1
15
48948
Fitting ............................................ 1
16
48958
Fitting ............................................ 2
The length listed in the component description
is the length of the hose only.
Refer to 207.1 to cross-reference Genie part
numbers to Parker part numbers.
