Welder Supplement
200 • Schematics and Hose Drawings
July 2004
202.1
S-60 and S-65 Hoses and Fittings
Rev A
Item
Part No.
Description
Qty.
1
89871-4048
Hose Assembly - Components:
Genie part numbers 48841,
48841 and 94358 @ 38 inches ... 2
2
48977
Fitting ............................................ 2
3
48948
Fitting ............................................ 1
4
49183-8492
Hose Assembly - Comonents:
Genie part numbers 48822,
48822 and 48756 @ 83 inches ... 1
5
48963
Fitting ............................................ 4
6
48933
Fitting ............................................ 1
7
48960
Fitting ............................................ 5
8
61072-2443
Hose Assembly - Components:
Genie part numbers 48841,
48845 and 48762 @ 21 inches ... 1
9
94374-6030
Hose Assembly - Components:
Genie part numbers 48841,
48846 and 94358 @ 57 inches ... 2
10
61072-2543
Hose Assembly - Components:
Genie part numbers 48841,
48845 and 48762 @ 22 inches ... 1
11
48941
Fitting ............................................ 1
12
48948
Fitting ............................................ 1
13
61610
Fitting ............................................ 1
The length listed in the component description
is the length of the hose only.
Refer to 207.1 to cross-reference Genie part
numbers to Parker part numbers.
