English – GIGABYTE 5225 User Manual
Page 74
Technical Reference
- 69 -
English
SPDIF Output Device (Optional Device)
3. Connect SPDIF to the SPDIF decoder.
1. Connect the SPDIF output device to the rear
bracket of PC, and fix it with screw.
2. Connect SPDIF device to the motherboard.
A "SPDIF output" device is available on the
motherboard. Cable with rear bracket is provided
and could link to the "SPDIF output" connector
(As picture.) For the further linkage to decoder,
rear bracket provides coaxial cable and Fiber
connecting port.
