- 52 -
GA-7N400E(-L) Motherboard
English
Frequency/Voltage Control
Figure 9: Frequency/Voltage Control
CM OS Setup Utility-Copyright (C) 1984-2003 Award Software
Frequency/Voltage Control
VCORE OverVoltage Control
Increase VCORE voltage may get stable for Over_Clock. But it may damage to CPU when enable
this feature.
Normal
Supply voltage as CPU reguired. (Default value)
+5% / +7.5% / +10%
Increase voltage range as user selected.
DIMM OverVoltage Control
Normal
Set DIMM OverVoltage Control to Normal. (Default value)
+0.1V
Set DIMM OverVoltage Control to +0.1V.
+0.2V
Set DIMM OverVoltage Control to +0.2V.
Incorrect using it m ay cause your system to fail. For power End-User use only!
AGP OverVoltage Control
Normal
Set AGP OverVoltage Control to Normal. (Default value)
+0.1V
Set AGP OverVoltage Control to +0.1V.
+0.2V
Set AGP OverVoltage Control to +0.2V.
+0.3V
Set AGP OverVoltage Control to +0.3V.
Incorrect using it m ay cause your system to fail. For power End-User use only!
VCORE OverVoltage Control
[Normal]
DIMM OverVoltage Control
[Normal]
AGP OverVoltage Control
[Normal]
Item Help
Menu Level
u
higf: Move Enter:Select +/-/PU/PD: Value F10: Save ESC:Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
