- 44 - GA-7N400E(-L) Motherboard
English
UR2 Duplex Mode
This feature allows you to seclect IR m ode.
This function will available when "UART Mode Select" doesn't set at "Normal" nor "SCR".
Half IR Function Duplex Half. (Default Value)
Full IR Function Duplex Full.
Onboard Parallel port
This feature allows you to select from a given set of parameters if the parallel port uses the onboard
I/O controller.
Disabled Disable onboard LPT port.
378/IRQ7 Enable onboard LPT port and address is 378, using IRQ7. (Default Value)
278/IRQ5 Enable onboard LPT port and address is 278, using IRQ5.
3BC/IRQ7 Enable onboard LPT port and address is 3BC, using IRQ7.
Parallel Port Mode
This feature allows you to connect with an advanced printer via the port mode it supports.
SPP Using Parallel port as Standard Parallel Port.
EPP Using Parallel port as Enhanced Parallel Port.
ECP Using Parallel port as Extended Capabilities Port. (Default Value)
ECP+EPP Using Parallel port as ECP & EPP mode.
ECP Mode Use DMA
This feature allows you to select Direct Memory Access(DMA) channel if the ECP mode selected.
This function will available when "Parallel Port M ode" set at ECP or ECP+EPP.
3 Set ECP M ode Use DM A to 3. (Default Value)
1 Set ECP Mode Use DM A to 1.
Game Port Address
Disabled Disable this function.
201 Set Gam e Port Address to 201. (Default Value)
209 Set Game Port Address to 209.
