Magnum 500-Series Switching Hubs Installation and User Guide (08/98)
GARRETT
4
2.0 INTRODUCTION
2.1 Inspecting the Package and Product
Examine the shipping container for obvious damage prior to installing this
product; notify the carrier of any damage which you believe occurred during shipment or
delivery. Inspect the contents of this package for any signs of damage and ensure that the
items listed below are included.
This package should contain:
1 Magnum 508, 528 or 528F Switching Hub
1 AC Power Cord (U.S. and other 115 VAC only)
1 Set of two wall-mounting brackets
1 Installation and User Guide (this manual), and Product Registration Card
Remove the items from the shipping container. Be sure to keep the shipping
container should you need to re-ship the unit at a later date. To validate the product
warranty, please complete and return the enclosed Product Registration Card to Garrett
Communications as soon as possible.
In the event there are items missing or damaged, contact the party from whom
you purchased the product. If the unit needs to be returned, please use the original
shipping container if possible. Refer to Section 5, Troubleshooting, for specific return
procedures.
2.2 Product Description - Magnum 500-Series Switching Hubs
The Magnum 500-Series Switching Hubs provide 8-port switching services to
enhance the performance of 10Mb Ethernet networks by segmenting the network traffic.
They may be used with existing Cat 3 cabling and shared 10b Ethernet hubs. On models
528 and 528F, there are two Fast Ethernet switched ports additionally that provide
100Mb switching services for high speed network connections. Full speed is maintained
across all ports, even when handling the smallest 64-byte frames.
All 10Mb ports in both units can auto-negotiate to either half- or full-duplex
mode. The copper Fast Ethernet ports on Model 528 & 528F are normally set for 100Mb
with manual selection of F/H duplex, but may be optionally set for auto-negotiation.
