GarrettCom 500-Series - Manual (Page 4)

Magnum 500-Series Switching Hubs Installation and User Guide (08/98)
GARRETT
iii
TABLE OF CONTENTS Page
1.0 SPECIFICATIONS .................................................................................... 1
1.1 Technical Specifications ................................................................................. 1
1.2 Ordering Information ...................................................................................... 3
2.0 INTRODUCTION...................................................................................... 4
2.1 Inspecting the Package and Product ............................................................... 4
2.2 Product Description - Magnum 500-Series Switching Hubs ......................... 4
2.2.1 Magnum 500-Series chassis ................................................................ 4
2.2.2 10 & 100Mb ports, full- or half-duplex and auto-negotiation modes . 6
2.2.3100Mb Fiber port, STor SC type(single mode or multi mode) 7
2.2.4 Frame Buffering and Latency............................................................. 7
2.3 Features and Benefits...................................................................................... 9
2.4 Applications.................................................................................................. 10
3.0 INSTALLATION ..................................................................................... 11
3.1 Locating the Magnum 500-Series Switching Hubs....................................... 11
3.1.1 Table-top or shelf mounting................................................................ 11
3.1.2 Wall (or Vertical) mounting................................................................ 12
3.1.3 Optional E-Stand ............................................................................... 12
3.2 Powering the Magnum 500-Series Switching Hubs ..................................... 13
3.3 Connecting Ethernet Media ………………………………………………...17
3.3.1 Connecting Twisted Pair (RJ-45, Cat 3, 5, UTP, STP) ...................... 17
3.3.2 Connecting Fiber Optic 100BASE-FX,Type ST & SC………18
3.4 Internal jumper settings for 100Mb ports, auto-negotiation ON or OFF ...... 18
4.0 OPERATION ........................................................................................... 19
4.1 Switching Funtionality, Filtering and Forwarding, Address learning ........... 20
4.2 Status LEDs .................................................................................................. 21
4.3 Manual switches for Up-link and Full/Half Duplex...................................... 21
4.4 Auto-negotiation option for copper Fast Ethernet ports .............................. 22
4.5 Auto-negotiation for 10Mb ports, half- or full-duplex mode ..................... 23
4.6 Collision-based Flow Control…………………………………….. 24
5.0 TROUBLESHOOTING ........................................................................... 25
5.1 Before Calling for Assistance ....................................................................... 26
5.2 When Calling for Assistance......................................................................... 27
5.3 Return Material Authorization (RMA) Procedure ........................................ 28
5.4 Shipping and Packaging Information............................................................ 28
A PPENDIX A: W ARRANTY I NFORMATION ....................................................... 29
A PPENDIX B : O PTIONAL 48V-DC POWER ADDENDUM .............................. 29
