Magnum 500-Series Switching Hubs Installation and User Guide (08/98)
GARRETT
3
1.2 Ordering Information
Magnum 500-Series Switching Hubs
MODEL DESCRIPTION
Magnum 528 Switching Hub, eight ports at 10Mb F/H plus two 100Mb
Fast Ethernet ports (F/H and 10/100). Self-learning 2K
node-capacity address table, Store and Forward operation
to filter all errored frames, full wire-speed filtering and
forwarding among all ports. Up-link switch on 10Mb port
# 8. Internal auto-ranging power supply.
(The copper Fast Ethernet ports can be manually set to
the desired mode, or may optionally be set for support of
10/100 and F/H IEEE 802.3u standard auto-negotiation).
Magnum 528F-SC Same as Model 528, but with a 100BASE-FX fiber port,
multi-mode SC connector, and a 100Mb RJ-45 port.
Magnum 528F-ST Same as Model 528, but with a 100BASE-FX fiber port,
multi-mode ST connector, and a 100Mb RJ-45 port.
Magnum 528F-SMSC Same as Model 528, but with a 100BASE-FX fiber port,
single-mode SC connector, and a 100Mb RJ-45 port.
Magnum 528F-SMST Same as Model 528, but with a 100BASE-FX fiber port,
single-mode ST connector, and a 100Mb RJ-45 port.
Magnum 508 Same as Model 528 but without the 2 Fast Ethernet ports
. Eight 10Mb switched ports (no 100Mb ports)
Garrett Communications reserves the right to change specifications, performance
characteristics and/or model offerings without notice.
